Ren Huizhong, Pyrialakos Georgios G, Zhong Qi, Wu Fan O, Khajavikhan Mercedeh, Christodoulides Demetrios N
Ming Hsieh Department of Electrical and Computer Engineering, University of Southern California, Los Angeles, CA, 90089, USA.
CREOL, College of Optics and Photonics, University of Central Florida, Orlando, FL, 32816, USA.
Light Sci Appl. 2025 May 12;14(1):188. doi: 10.1038/s41377-025-01856-4.
Frequency generation in highly multimode nonlinear optical systems is inherently a complex process, giving rise to an exceedingly convoluted landscape of evolution dynamics. While predicting and controlling the global conversion efficiencies in such nonlinear environments has long been considered impossible, here, we formally address this challenge even in scenarios involving a very large number of spatial modes. By utilizing fundamental notions from optical statistical mechanics, we develop a universal theoretical framework that effectively treats all frequency components as chemical reactants/products, capable of undergoing optical thermodynamic reactions facilitated by a variety of multi-wave mixing effects. These photon-photon reactions are governed by conservation laws that directly determine the optical temperatures and chemical potentials of the ensued chemical equilibria for each frequency species. In this context, we develop a comprehensive stoichiometric model and formally derive an expression that relates the chemical potentials to the optical stoichiometric coefficients, in a manner akin to atomic/molecular chemical reactions. This advancement unlocks new predictive capabilities that can facilitate the optimization of frequency generation in highly multimode photonic arrangements, surpassing the limitations of conventional schemes that rely exclusively on nonlinear optical dynamics. Notably, we identify a universal regime of Rayleigh-Jeans thermalization where an optical reaction at near-zero optical temperatures can promote the complete and entropically irreversible conversion of light to the fundamental mode at a target frequency. Our theoretical results are corroborated by numerical simulations in settings where second-harmonic generation, sum-frequency generation and four-wave mixing processes can manifest.
在高度多模非线性光学系统中产生频率本质上是一个复杂的过程,会产生极其复杂的演化动力学图景。虽然长期以来人们一直认为在这种非线性环境中预测和控制全局转换效率是不可能的,但在此我们正式应对这一挑战,即使是在涉及大量空间模式的情况下。通过利用光学统计力学的基本概念,我们开发了一个通用的理论框架,该框架有效地将所有频率成分视为化学反应物/产物,能够通过各种多波混频效应进行光热动力学反应。这些光子 - 光子反应受守恒定律支配,这些定律直接决定了每种频率成分所产生的化学平衡的光学温度和化学势。在此背景下,我们开发了一个全面的化学计量模型,并正式推导出一个将化学势与光学化学计量系数相关联的表达式,其方式类似于原子/分子化学反应。这一进展开启了新的预测能力,有助于优化高度多模光子装置中的频率产生,超越了仅依赖非线性光学动力学的传统方案的局限性。值得注意的是,我们确定了瑞利 - 金斯热化的通用区域,其中在接近零光学温度下的光反应可以促进光完全且熵不可逆地转换为目标频率的基模。我们的理论结果在能够表现出二次谐波产生、和频产生以及四波混频过程的数值模拟中得到了证实。
