Baillif P, Touray J C
URA du CNRS et GDR, ESEM, Université d'Orléans, France.
Environ Health Perspect. 1994 Oct;102 Suppl 5(Suppl 5):77-81. doi: 10.1289/ehp.94102s577.
The dissolution of textile glass fibers of four different compositions has been investigated at 37 degrees C. In these glasses, which are isolation type, the P2O5 contents scatter between 0 and 2 wt% and Al2O3 from 0.12 to 3.4 wt%. Both static (30-mg fibers; 250-ml solution) and dynamic (50-mg fibers; 40 ml/day flow rate) conditions with or without bubbling of a gas mixture (95:5, N2-CO2) have been used. Two physiological solutions, one proposed by Kanapilly and the other by Scholtze, were used. After each run (1, 3, 7, 14, and sometimes 30, 62 days) the solutions were analyzed for B and Si by inductively coupled plasma (ICP), the weight losses were determined, and the residual solid were observed by scanning electron microscopy (SEM) and X-ray photoelectron spectroscopy (XPS). Static runs give a better agreement between measured and calculated weight losses from solution analyses than dynamic experiments. SEM examinations indicate diameter reduction and formation of a hydrated Si-rich layer. Sometimes hollow tubes, suggesting the detachment of these layers, are observed. XPS and energy dispersive X-ray (EDX) analysis indicate the formation of a veneer of calcium phosphate for the most rapidly dissolving glass. In other cases an Al increase is observed at the solid solution interface. Whatever experimental conditions are used, the relative dissolution rates of the four glasses are identical. The kinetics may be modeled with variable dissolution rates from initial high values to final low ones. The latter reflect the very low solubility of the residual product.
在37摄氏度下对四种不同成分的纺织玻璃纤维的溶解情况进行了研究。在这些属于隔离型的玻璃中,P2O5含量在0至2重量%之间波动,Al2O3含量在0.12至3.4重量%之间。使用了静态(30毫克纤维;250毫升溶液)和动态(50毫克纤维;流速40毫升/天)条件,有或没有混合气体(95:5,N2 - CO2)鼓泡。使用了两种生理溶液,一种是卡纳皮利提出的,另一种是朔尔策提出的。每次实验运行(1、3、7、14天,有时还有30、62天)后,通过电感耦合等离子体(ICP)分析溶液中的硼和硅,测定重量损失,并通过扫描电子显微镜(SEM)和X射线光电子能谱(XPS)观察残留固体。与动态实验相比,静态实验在溶液分析测量和计算的重量损失之间给出了更好的一致性。SEM检查表明纤维直径减小并形成了富含硅的水合层。有时会观察到空心管,这表明这些层发生了分离。XPS和能量色散X射线(EDX)分析表明,对于溶解最快的玻璃,形成了磷酸钙表层。在其他情况下,在固 - 液界面观察到铝含量增加。无论使用何种实验条件,这四种玻璃的相对溶解速率都是相同的。动力学可以用从初始高值到最终低值的可变溶解速率来建模。后者反映了残留产物的极低溶解度。
