Omelon Sidney, Georgiou John, Henneman Zachary J, Wise Lisa M, Sukhu Balram, Hunt Tanya, Wynnyckyj Chrystia, Holmyard Douglas, Bielecki Ryszard, Grynpas Marc D
Samuel Lunenfeld Research Institute, Mt. Sinai Hospital, Toronto, Canada.
PLoS One. 2009 May 20;4(5):e5634. doi: 10.1371/journal.pone.0005634.
Skeletons are formed in a wide variety of shapes, sizes, and compositions of organic and mineral components. Many invertebrate skeletons are constructed from carbonate or silicate minerals, whereas vertebrate skeletons are instead composed of a calcium phosphate mineral known as apatite. No one yet knows why the dynamic vertebrate skeleton, which is continually rebuilt, repaired, and resorbed during growth and normal remodeling, is composed of apatite. Nor is the control of bone and calcifying cartilage mineralization well understood, though it is thought to be associated with phosphate-cleaving proteins. Researchers have assumed that skeletal mineralization is also associated with non-crystalline, calcium- and phosphate-containing electron-dense granules that have been detected in vertebrate skeletal tissue prepared under non-aqueous conditions. Again, however, the role of these granules remains poorly understood. Here, we review bone and growth plate mineralization before showing that polymers of phosphate ions (polyphosphates: (PO(3)(-))(n)) are co-located with mineralizing cartilage and resorbing bone. We propose that the electron-dense granules contain polyphosphates, and explain how these polyphosphates may play an important role in apatite biomineralization.
PRINCIPAL FINDINGS/METHODOLOGY: The enzymatic formation (condensation) and destruction (hydrolytic degradation) of polyphosphates offers a simple mechanism for enzymatic control of phosphate accumulation and the relative saturation of apatite. Under circumstances in which apatite mineral formation is undesirable, such as within cartilage tissue or during bone resorption, the production of polyphosphates reduces the free orthophosphate (PO(4)(3-)) concentration while permitting the accumulation of a high total PO(4)(3-) concentration. Sequestering calcium into amorphous calcium polyphosphate complexes can reduce the concentration of free calcium. The resulting reduction of both free PO(4)(3-) and free calcium lowers the relative apatite saturation, preventing formation of apatite crystals. Identified in situ within resorbing bone and mineralizing cartilage by the fluorescent reporter DAPI (4',6-diamidino-2-phenylindole), polyphosphate formation prevents apatite crystal precipitation while accumulating high local concentrations of total calcium and phosphate. When mineralization is required, tissue non-specific alkaline phosphatase, an enzyme associated with skeletal and cartilage mineralization, cleaves orthophosphates from polyphosphates. The hydrolytic degradation of polyphosphates in the calcium-polyphosphate complex increases orthophosphate and calcium concentrations and thereby favors apatite mineral formation. The correlation of alkaline phosphatase with this process may be explained by the destruction of polyphosphates in calcifying cartilage and areas of bone formation.
CONCLUSIONS/SIGNIFICANCE: We hypothesize that polyphosphate formation and hydrolytic degradation constitute a simple mechanism for phosphate accumulation and enzymatic control of biological apatite saturation. This enzymatic control of calcified tissue mineralization may have permitted the development of a phosphate-based, mineralized endoskeleton that can be continually remodeled.
骨骼具有各种各样的形状、大小以及有机和矿物质成分的组成。许多无脊椎动物的骨骼由碳酸盐或硅酸盐矿物构成,而脊椎动物的骨骼则由一种名为磷灰石的磷酸钙矿物组成。目前尚无人知晓为何在生长和正常重塑过程中不断进行重建、修复和再吸收的动态脊椎动物骨骼是由磷灰石构成的。尽管人们认为骨和钙化软骨矿化与磷酸裂解蛋白有关,但对其控制机制仍知之甚少。研究人员假定骨骼矿化也与在非水条件下制备的脊椎动物骨骼组织中检测到的非晶态、含钙和磷的电子致密颗粒有关。然而,这些颗粒的作用仍然了解不足。在此,我们在展示磷酸根离子聚合物(多磷酸盐:(PO(3)(-))(n))与矿化软骨和再吸收骨共定位之前,先对骨和生长板矿化进行综述。我们提出电子致密颗粒含有多磷酸盐,并解释了这些多磷酸盐如何可能在磷灰石生物矿化中发挥重要作用。
主要发现/方法:多磷酸盐的酶促形成(缩合)和破坏(水解降解)为磷酸积累和磷灰石相对饱和度的酶促控制提供了一种简单机制。在诸如软骨组织内或骨吸收期间等不需要形成磷灰石矿物的情况下,多磷酸盐的产生会降低游离正磷酸盐(PO(4)(3-))浓度,同时允许高总PO(4)(3-)浓度的积累。将钙螯合到无定形多磷酸钙复合物中可降低游离钙的浓度。由此导致的游离PO(4)(3-)和游离钙的减少会降低磷灰石的相对饱和度,从而防止磷灰石晶体的形成。通过荧光报告分子DAPI(4',6-二脒基-2-苯基吲哚)在再吸收骨和矿化软骨中原位鉴定,多磷酸盐的形成可防止磷灰石晶体沉淀,同时积累高局部浓度的总钙和磷。当需要矿化时,组织非特异性碱性磷酸酶(一种与骨骼和软骨矿化相关的酶)会从多磷酸盐中裂解出正磷酸盐。钙-多磷酸盐复合物中多磷酸盐的水解降解会增加正磷酸盐和钙的浓度,从而有利于磷灰石矿物的形成。碱性磷酸酶与这一过程的相关性可能是由于钙化软骨和骨形成区域中多磷酸盐的破坏所致。
结论/意义:我们假设多磷酸盐的形成和水解降解构成了一种简单的机制,用于磷酸积累和对生物磷灰石饱和度的酶促控制。这种对钙化组织矿化的酶促控制可能使得基于磷酸盐的矿化内骨骼得以发展,并且可以不断进行重塑。
