University of Edinburgh/British Heart Foundation Centre for Cardiovascular Science, Edinburgh, UK.
Clin Radiol. 2013 Nov;68(11):e570-7. doi: 10.1016/j.crad.2013.05.098. Epub 2013 Jul 6.
To assess the effect of two iterative reconstruction algorithms (AIDR and AIDR3D) and individualized automatic tube current selection on radiation dose and image quality in computed tomography coronary angiography (CTCA).
In a single-centre cohort study, 942 patients underwent electrocardiogram-gated CTCA using a 320-multidetector CT system. Images from group 1 (n = 228) were reconstructed with a filtered back projection algorithm (Quantum Denoising Software, QDS+). Iterative reconstruction was used for group 2 (AIDR, n = 379) and group 3 (AIDR3D, n = 335). Tube current was selected based on body mass index (BMI) for groups 1 and 2, and selected automatically based on scout image attenuation for group 3. Subjective image quality was graded on a four-point scale (1 = excellent, 4 = non-diagnostic).
There were no differences in age (p = 0.975), body mass index (p = 0.435), or heart rate (p = 0.746) between the groups. Image quality improved with iterative reconstruction and automatic tube current selection [1.3 (95% confidence intervals (CI): 1.2-1.4), 1.2 (1.1-1.2) and 1.1 (1-1.2) respectively; p < 0.001] and radiation dose decreased [274 (260-290), 242 (230-253) and 168 (156-180) mGy cm, respectively; p < 0.001].
The application of the latest iterative reconstruction algorithm and individualized automatic tube current selection can substantially reduce radiation dose whilst improving image quality in CTCA.
评估两种迭代重建算法(AIDR 和 AIDR3D)和个体化自动管电流选择对冠状动脉 CT 血管造影(CTCA)中辐射剂量和图像质量的影响。
在一项单中心队列研究中,942 例患者使用 320 层多排 CT 系统进行心电门控 CTCA。第 1 组(n=228)的图像使用滤波反投影算法(量子降噪软件,QDS+)重建。第 2 组(AIDR,n=379)和第 3 组(AIDR3D,n=335)使用迭代重建。第 1 组和第 2 组根据体重指数(BMI)选择管电流,第 3 组根据扫描图像衰减自动选择管电流。主观图像质量按 4 分制评分(1=优秀,4=不可诊断)。
各组间年龄(p=0.975)、体重指数(p=0.435)和心率(p=0.746)无差异。迭代重建和自动管电流选择可提高图像质量[分别为 1.3(95%置信区间(CI):1.2-1.4)、1.2(1.1-1.2)和 1.1(1-1.2);p<0.001],且降低辐射剂量[分别为 274(260-290)、242(230-253)和 168(156-180)mGy·cm;p<0.001]。
应用最新的迭代重建算法和个体化自动管电流选择可显著降低 CTCA 的辐射剂量,同时提高图像质量。
