一种用于使用可穿戴光电容积脉搏波传感器在剧烈体育活动期间重建受运动伪影干扰的心率信号的新型时变频谱滤波算法。

A Novel Time-Varying Spectral Filtering Algorithm for Reconstruction of Motion Artifact Corrupted Heart Rate Signals During Intense Physical Activities Using a Wearable Photoplethysmogram Sensor.

作者信息

Salehizadeh Seyed M A, Dao Duy, Bolkhovsky Jeffrey, Cho Chae, Mendelson Yitzhak, Chon Ki H

机构信息

Department of Biomedical Engineering, University of Connecticut, Storrs, CT 06269, USA.

Department of Biomedical Engineering, Worcester Polytechnic Institution, Worcester, MA 01609, USA.

出版信息

Sensors (Basel). 2015 Dec 23;16(1):10. doi: 10.3390/s16010010.

Abstract

Accurate estimation of heart rates from photoplethysmogram (PPG) signals during intense physical activity is a very challenging problem. This is because strenuous and high intensity exercise can result in severe motion artifacts in PPG signals, making accurate heart rate (HR) estimation difficult. In this study we investigated a novel technique to accurately reconstruct motion-corrupted PPG signals and HR based on time-varying spectral analysis. The algorithm is called Spectral filter algorithm for Motion Artifacts and heart rate reconstruction (SpaMA). The idea is to calculate the power spectral density of both PPG and accelerometer signals for each time shift of a windowed data segment. By comparing time-varying spectra of PPG and accelerometer data, those frequency peaks resulting from motion artifacts can be distinguished from the PPG spectrum. The SpaMA approach was applied to three different datasets and four types of activities: (1) training datasets from the 2015 IEEE Signal Process. Cup Database recorded from 12 subjects while performing treadmill exercise from 1 km/h to 15 km/h; (2) test datasets from the 2015 IEEE Signal Process. Cup Database recorded from 11 subjects while performing forearm and upper arm exercise. (3) Chon Lab dataset including 10 min recordings from 10 subjects during treadmill exercise. The ECG signals from all three datasets provided the reference HRs which were used to determine the accuracy of our SpaMA algorithm. The performance of the SpaMA approach was calculated by computing the mean absolute error between the estimated HR from the PPG and the reference HR from the ECG. The average estimation errors using our method on the first, second and third datasets are 0.89, 1.93 and 1.38 beats/min respectively, while the overall error on all 33 subjects is 1.86 beats/min and the performance on only treadmill experiment datasets (22 subjects) is 1.11 beats/min. Moreover, it was found that dynamics of heart rate variability can be accurately captured using the algorithm where the mean Pearson's correlation coefficient between the power spectral densities of the reference and the reconstructed heart rate time series was found to be 0.98. These results show that the SpaMA method has a potential for PPG-based HR monitoring in wearable devices for fitness tracking and health monitoring during intense physical activities.

摘要

在剧烈体育活动期间从光电容积脉搏波图(PPG)信号准确估计心率是一个极具挑战性的问题。这是因为剧烈和高强度运动可导致PPG信号中出现严重的运动伪影,使得准确估计心率(HR)变得困难。在本研究中,我们研究了一种基于时变频谱分析准确重建受运动干扰的PPG信号和心率的新技术。该算法称为用于运动伪影和心率重建的频谱滤波算法(SpaMA)。其思路是针对加窗数据段的每个时移计算PPG信号和加速度计信号的功率谱密度。通过比较PPG和加速度计数据的时变频谱,可以将由运动伪影产生的频率峰值与PPG频谱区分开来。SpaMA方法应用于三个不同的数据集和四种活动类型:(1)来自2015年IEEE信号处理杯数据库的训练数据集,记录了12名受试者在跑步机上以1公里/小时至15公里/小时速度运动时的情况;(2)来自2015年IEEE信号处理杯数据库的测试数据集,记录了11名受试者在前臂和上臂运动时的情况。(3)Chon实验室数据集,包括10名受试者在跑步机运动期间的10分钟记录。来自所有三个数据集的心电图信号提供了参考心率,用于确定我们的SpaMA算法的准确性。SpaMA方法的性能通过计算从PPG估计的心率与来自心电图的参考心率之间的平均绝对误差来计算。使用我们的方法在第一个、第二个和第三个数据集上的平均估计误差分别为0.89、1.93和1.38次/分钟,而在所有33名受试者上的总体误差为1.86次/分钟,仅在跑步机实验数据集(22名受试者)上的性能为1.11次/分钟。此外,发现使用该算法可以准确捕获心率变异性的动态变化,其中参考心率和重建心率时间序列的功率谱密度之间的平均皮尔逊相关系数为0.98。这些结果表明,SpaMA方法在可穿戴设备中基于PPG进行心率监测以用于剧烈体育活动期间的健身跟踪和健康监测方面具有潜力。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/4ea6/4732043/7e57a1d4cdb4/sensors-16-00010-g001.jpg
