基于电子舌结合稳健偏最小二乘回归法对中药苦味的评价
Evaluation of the Bitterness of Traditional Chinese Medicines using an E-Tongue Coupled with a Robust Partial Least Squares Regression Method.
作者信息
Lin Zhaozhou, Zhang Qiao, Liu Ruixin, Gao Xiaojie, Zhang Lu, Kang Bingya, Shi Junhan, Wu Zidan, Gui Xinjing, Li Xuelin
机构信息
Institute of Clinical Pharmacy, Beijing Municipal Health Bureau, Beijing 100035, China.
School of Chinese Materia Medica, Beijing University of Chinese Medicine, Beijing 100102, China.
出版信息
Sensors (Basel). 2016 Jan 25;16(2):151. doi: 10.3390/s16020151.
To accurately, safely, and efficiently evaluate the bitterness of Traditional Chinese Medicines (TCMs), a robust predictor was developed using robust partial least squares (RPLS) regression method based on data obtained from an electronic tongue (e-tongue) system. The data quality was verified by the Grubb's test. Moreover, potential outliers were detected based on both the standardized residual and score distance calculated for each sample. The performance of RPLS on the dataset before and after outlier detection was compared to other state-of-the-art methods including multivariate linear regression, least squares support vector machine, and the plain partial least squares regression. Both R² and root-mean-squares error (RMSE) of cross-validation (CV) were recorded for each model. With four latent variables, a robust RMSECV value of 0.3916 with bitterness values ranging from 0.63 to 4.78 were obtained for the RPLS model that was constructed based on the dataset including outliers. Meanwhile, the RMSECV, which was calculated using the models constructed by other methods, was larger than that of the RPLS model. After six outliers were excluded, the performance of all benchmark methods markedly improved, but the difference between the RPLS model constructed before and after outlier exclusion was negligible. In conclusion, the bitterness of TCM decoctions can be accurately evaluated with the RPLS model constructed using e-tongue data.
为了准确、安全且高效地评估中药的苦味,基于从电子舌系统获得的数据,使用稳健偏最小二乘(RPLS)回归方法开发了一种稳健的预测模型。通过格拉布斯检验验证数据质量。此外,基于为每个样本计算的标准化残差和得分距离检测潜在的异常值。将异常值检测前后数据集上RPLS的性能与其他先进方法进行比较,包括多元线性回归、最小二乘支持向量机和平凡偏最小二乘回归。记录每个模型的交叉验证(CV)的R²和均方根误差(RMSE)。对于基于包含异常值的数据集构建的RPLS模型,使用四个潜变量,得到了稳健的RMSECV值0.3916,苦味值范围为0.63至4.78。同时,使用其他方法构建的模型计算出的RMSECV大于RPLS模型的RMSECV。排除六个异常值后,所有基准方法的性能均显著提高,但异常值排除前后构建的RPLS模型之间的差异可忽略不计。总之,使用基于电子舌数据构建的RPLS模型可以准确评估中药汤剂的苦味。
