Huang Zhen-Guo, Gao Bao-Xiang, Chen He, Yang Min-Xing, Chen Xiao-Liang, Yan Ran, Lu Xin, Shi Kai-Ning, Chan Queenie, Wang Guo-Chun
Department of Radiology, China-Japan Friendship Hospital, Beijing, China.
Department of Rheumatology, China-Japan Friendship Hospital, Beijing, China.
PLoS One. 2017 Jul 17;12(7):e0181069. doi: 10.1371/journal.pone.0181069. eCollection 2017.
To evaluate the value of whole-body magnetic resonance imaging (WBMRI) in diagnosing muscular and extra muscular lesions in patients with polymyositis (PM) and dermatomyositis (DM).
A retrospective analysis of WBMRI data from PM/DM patients who met the Bohan and Peter diagnostic criteria was performed. X2 test was used to compare the rate of positive diagnosis of newly diagnosed patients using WBMRI, serum creatine kinase test, and EMG. McNemar test was used to compare the performance of WBMRI and chest CT in detecting interstitial lung disease (ILD).
The study included 129 patients (30 PM cases and 99 DM cases). Of them, 81.4% (105/129) showed a visible inflammatory muscular edema on their WBMRI; 29.5% (38/129) had varying degrees of fatty infiltration (9 cases with clear muscular atrophy). Of the 66 newly diagnosed patients, the positive rates of WBMRI, muscle biopsy, serum creatine kinase test and EMG were 86.4% (57/66), 92.4% (61/66), 71.2% (47/66) and 71.1% (32/45), respectively. There was no significant difference in the positive rates between WBMRI and muscle biopsy (X2 = 1.28, P = 0.258). The WBMRI had a higher positive rate than both serum creatine kinase test (X2 = 4.53, P = 0.033) and EMG (X2 = 3.92, P = 0.047). In addition to muscular changes, WBMRI also detected interstitial lung disease (ILD) in 38 cases (29.5%), osteonecrosis in 15 cases (11.6%), and neoplastic lesions (5 malignant; 7 benign) in 12 cases (9.3%). Of the 61 patients who underwent routine chest CT examinations, the WBMRI and CT revealed ILD in 29 cases and 35 cases respectively. There was no significant difference in the sensitivity between WBMRI and CT (p = 0.146).
WBMRI is a sensitive, non-invasive and efficient imaging method. It comprehensively displays the extent of muscular involvement in PM/DM patients, and it has the ability to diagnose other associated extra muscular diseases, such as ILD and systemic malignancy. WBMRI can also help screen steroid-induced osteonecrosis.
评估全身磁共振成像(WBMRI)在诊断多发性肌炎(PM)和皮肌炎(DM)患者肌肉及肌肉外病变中的价值。
对符合博汉和彼得诊断标准的PM/DM患者的WBMRI数据进行回顾性分析。采用X2检验比较新诊断患者使用WBMRI、血清肌酸激酶检测和肌电图的阳性诊断率。采用McNemar检验比较WBMRI和胸部CT在检测间质性肺疾病(ILD)方面的表现。
该研究纳入129例患者(30例PM患者和99例DM患者)。其中,81.4%(105/129)在WBMRI上显示可见的炎性肌肉水肿;29.5%(38/129)有不同程度的脂肪浸润(9例有明显肌肉萎缩)。在66例新诊断患者中,WBMRI、肌肉活检、血清肌酸激酶检测和肌电图的阳性率分别为86.4%(57/66)、92.4%(61/66)、71.2%(47/66)和71.1%(32/45)。WBMRI与肌肉活检的阳性率无显著差异(X2 = 1.28,P = 0.258)。WBMRI的阳性率高于血清肌酸激酶检测(X2 = 4.53,P = 0.033)和肌电图(X2 = 3.92,P = 0.047)。除肌肉改变外,WBMRI还检测到38例(29.5%)间质性肺疾病(ILD)、15例(11.6%)骨坏死和12例(9.3%)肿瘤性病变(5例恶性;7例良性)。在61例行常规胸部CT检查的患者中,WBMRI和CT分别发现29例和35例ILD。WBMRI和CT的敏感性无显著差异(p = 0.146)。
WBMRI是一种敏感、无创且高效的成像方法。它能全面显示PM/DM患者肌肉受累的程度,并有能力诊断其他相关的肌肉外疾病,如ILD和系统性恶性肿瘤。WBMRI还可有助于筛查类固醇诱导的骨坏死。
