Bixner Oliver, Kurzhals Steffen, Virk Mudassar, Reimhult Erik
Institute for Biologically Inspired Materials, Department of Nanobiotechnology, University of Natural Resources and Life Sciences, Vienna, Muthgasse 11, Vienna 1190, Austria.
School of Materials Science and Engineering, Centre for Biomimetic Sensor Science, Nanyang Technological University, 50 Nanyang Drive, 637553 Singapore.
Materials (Basel). 2016 Jan 6;9(1):29. doi: 10.3390/ma9010029.
Magnetic polymersomes were prepared by self-assembly of the amphiphilic block copolymer poly(isoprene---isopropylacrylamide) with monodisperse hydrophobic superparamagnetic iron oxide nanoparticles (SPION). The specifically designed thermoresponsive block copolymer allowed for efficient incorporation of the hydrophobic nanoparticles in the membrane core and encapsulation of the water soluble dye calcein in the lumen of the vesicles. Magnetic heating of the embedded SPIONs led to increased bilayer permeability through dehydration of the thermoresponsive PNIPAM block. The entrapped calcein could therefore be released in controlled doses solely through exposure to pulses of an alternating magnetic field. This hybrid SPION-polymersome system demonstrates a possible direction for release applications that merges rational polymersome design with addressed external magnetic field-triggered release through embedded nanomaterials.
磁性聚合物囊泡是通过两亲性嵌段共聚物聚(异戊二烯-异丙基丙烯酰胺)与单分散疏水性超顺磁性氧化铁纳米颗粒(SPION)自组装制备而成。这种经过特殊设计的热响应性嵌段共聚物能够有效地将疏水性纳米颗粒纳入膜核心,并将水溶性染料钙黄绿素包裹在囊泡腔内。嵌入的SPIONs的磁热作用通过热响应性PNIPAM嵌段的脱水导致双层膜通透性增加。因此,仅通过暴露于交变磁场脉冲,包封的钙黄绿素就可以以可控剂量释放。这种SPION-聚合物囊泡混合系统展示了一种释放应用的可能方向,即将合理的聚合物囊泡设计与通过嵌入纳米材料实现的外部磁场触发释放相结合。
