基于类真实金属纤维素纸的柔性超级电容器电极。

Flexible supercapacitor electrodes based on real metal-like cellulose papers.

作者信息

Ko Yongmin, Kwon Minseong, Bae Wan Ki, Lee Byeongyong, Lee Seung Woo, Cho Jinhan

机构信息

Department of Chemical and Biological Engineering, Korea University, 145 Anam-ro, Seongbuk-gu, Seoul, 02841, Republic of Korea.

Photoelectronic Hybrids Research Center, Korea Institute of Science and Technology (KIST), Seoul, 02792, Republic of Korea.

出版信息

Nat Commun. 2017 Sep 14;8(1):536. doi: 10.1038/s41467-017-00550-3.

Abstract

The effective implantation of conductive and charge storage materials into flexible frames has been strongly demanded for the development of flexible supercapacitors. Here, we introduce metallic cellulose paper-based supercapacitor electrodes with excellent energy storage performance by minimizing the contact resistance between neighboring metal and/or metal oxide nanoparticles using an assembly approach, called ligand-mediated layer-by-layer assembly. This approach can convert the insulating paper to the highly porous metallic paper with large surface areas that can function as current collectors and nanoparticle reservoirs for supercapacitor electrodes. Moreover, we demonstrate that the alternating structure design of the metal and pseudocapacitive nanoparticles on the metallic papers can remarkably increase the areal capacitance and rate capability with a notable decrease in the internal resistance. The maximum power and energy density of the metallic paper-based supercapacitors are estimated to be 15.1 mW cm and 267.3 μWh cm, respectively, substantially outperforming the performance of conventional paper or textile-type supercapacitors.With ligand-mediated layer-by-layer assembly between metal nanoparticles and small organic molecules, the authors prepare metallic paper electrodes for supercapacitors with high power and energy densities. This approach could be extended to various electrodes for portable/wearable electronics.

摘要

为了开发柔性超级电容器,强烈需要将导电和电荷存储材料有效地植入柔性框架中。在此,我们通过一种称为配体介导的逐层组装的组装方法,将相邻金属和/或金属氧化物纳米颗粒之间的接触电阻降至最低,从而引入具有优异储能性能的金属纤维素纸基超级电容器电极。这种方法可以将绝缘纸转化为具有大表面积的高度多孔金属纸,其可作为超级电容器电极的集流体和纳米颗粒储存库。此外,我们证明了金属纸上金属和赝电容纳米颗粒的交替结构设计可以显著提高面积电容和倍率性能,同时内阻显著降低。基于金属纸的超级电容器的最大功率和能量密度估计分别为15.1 mW cm和267.3 μWh cm,大大优于传统纸或纺织型超级电容器的性能。通过金属纳米颗粒和小有机分子之间的配体介导逐层组装,作者制备了具有高功率和能量密度的超级电容器金属纸电极。这种方法可以扩展到用于便携式/可穿戴电子产品的各种电极。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e340/5599591/f34e4aa5f064/41467_2017_550_Fig1_HTML.jpg
