Li Xing, Bai Yongshun, Wang Mingshan, Wang Guoliang, Ma Yan, Huang Yun, Zheng Jianming
The Center of New Energy Materials and Technology, School of Materials Science and Engineering, Southwest Petroleum University, Chengdu 610500, Sichuan, China.
Research Institute (RI), NingDe Amperex Technology Limited, Ningde 352100, Fujian, China.
Nanomaterials (Basel). 2019 Apr 23;9(4):650. doi: 10.3390/nano9040650.
Silicon is the one of the most promising anode material alternatives for next-generation lithium-ion batteries. However, the low electronic conductivity, unstable formation of solid electrolyte interphase, and the extremely high volume expansion (up to 300%) which results in pulverization of Si and rapid fading of its capacity have been identified as primary reasons for hindering its application. In this work, we put forward to introduce dual carbonaceous materials synergetic protection to overcome the drawbacks of the silicon anode. The silicon nanoparticle was coated by pyrolysed carbon, and meanwhile anchored on the surface of reduced graphene oxide, to form a self-standing film composite (C@Si/rGO). The C@Si/rGO film electrode displays high flexibility and an ordered porous structure, which could not only buffer the Si nanoparticle expansion during lithiation/delithiation processes, but also provides the channels for fast electron transfer and lithium ion transport. Therefore, the self-standing C@Si/rGO film electrode shows a high reversible capacity of 1002 mAh g over 100 cycles and exhibits much better rate capability, validating it as a promising anode for constructing high performance lithium-ion batteries.
硅是下一代锂离子电池最有前景的负极材料替代品之一。然而,低电子导电性、固体电解质界面的不稳定形成以及极高的体积膨胀(高达300%)导致硅粉化及其容量快速衰减,这些已被确定为阻碍其应用的主要原因。在这项工作中,我们提出引入双碳质材料协同保护以克服硅负极的缺点。硅纳米颗粒被热解碳包覆,同时锚定在还原氧化石墨烯表面,形成自支撑膜复合材料(C@Si/rGO)。C@Si/rGO膜电极具有高柔韧性和有序多孔结构,这不仅可以缓冲锂化/脱锂过程中硅纳米颗粒的膨胀,还能提供快速电子转移和锂离子传输的通道。因此,自支撑C@Si/rGO膜电极在100次循环中显示出1002 mAh g的高可逆容量,并表现出更好的倍率性能,证明它是构建高性能锂离子电池的有前景的负极材料。
