Ren Shuai, Zhao Rui, Cui Wenjing, Qiu Wenli, Guo Kai, Cao Yingying, Duan Shaofeng, Wang Zhongqiu, Chen Rong
Department of Radiology, The Eighth Affiliated Hospital, Sun Yat-Sen University, Shenzhen, China.
Department of Radiology, Affiliated Hospital of Nanjing University of Chinese Medicine, Nanjing, China.
Front Oncol. 2020 Aug 25;10:1618. doi: 10.3389/fonc.2020.01618. eCollection 2020.
The purpose was to assess the predictive ability of computed tomography (CT)-based radiomics signature in differential diagnosis between pancreatic adenosquamous carcinoma (PASC) and pancreatic ductal adenocarcinoma (PDAC).
Eighty-one patients (63.6 ± 8.8 years old) with PDAC and 31 patients (64.7 ± 11.1 years old) with PASC who underwent preoperative CE-CT were included. A total of 792 radiomics features were extracted from the late arterial phase ( = 396) and portal venous phase ( = 396) for each case. Significantly different features were selected using Mann-Whitney test, univariate logistic regression analysis, and minimum redundancy and maximum relevance method. A radiomics signature was constructed using random forest method, the robustness and the reliability of which was validated using 10-times leave group out cross-validation (LGOCV) method.
Seven radiomics features from late arterial phase images and three from portal venous phase images were finally selected. The radiomics signature performed well in differential diagnosis between PASC and PDAC, with 94.5% accuracy, 98.3% sensitivity, 90.1% specificity, 91.9% positive predictive value (PPV), and 97.8% negative predictive value (NPV). Moreover, the radiomics signature was proved to be robust and reliable using the LGOCV method, with 76.4% accuracy, 91.1% sensitivity, 70.8% specificity, 56.7% PPV, and 96.2% NPV.
CT-based radiomics signature may serve as a promising non-invasive method in differential diagnosis between PASC and PDAC.
评估基于计算机断层扫描(CT)的影像组学特征在胰腺腺鳞癌(PASC)与胰腺导管腺癌(PDAC)鉴别诊断中的预测能力。
纳入81例接受术前增强CT的PDAC患者(年龄63.6±8.8岁)和31例PASC患者(年龄64.7±11.1岁)。对每例患者在动脉晚期(n = 396)和门静脉期(n = 396)提取总共792个影像组学特征。使用曼-惠特尼U检验、单因素逻辑回归分析以及最小冗余最大相关法选择显著不同的特征。采用随机森林法构建影像组学特征,并使用10次留组交叉验证(LGOCV)法验证其稳健性和可靠性。
最终从动脉晚期图像中选择了7个影像组学特征,从门静脉期图像中选择了3个。该影像组学特征在PASC和PDAC的鉴别诊断中表现良好,准确率为94.5%,灵敏度为98.3%,特异度为90.1%,阳性预测值(PPV)为91.9%,阴性预测值(NPV)为97.8%。此外,使用LGOCV法证明该影像组学特征具有稳健性和可靠性,准确率为76.4%,灵敏度为91.1%,特异度为70.8%,PPV为56.7%,NPV为96.2%。
基于CT的影像组学特征可能是PASC和PDAC鉴别诊断中有前景的非侵入性方法。
