BACKGROUND: An increasing number of eHealth interventions aim to support healthy behaviors that facilitate weight loss. However, there is limited evidence of the effectiveness of the interventions and little focus on weight loss maintenance. Knowledge about end user values and needs is essential to create meaningful and effective eHealth interventions, and to identify persuasive system design (PSD) principles and behavior change techniques (BCTs) that may contribute to the behavior change required for successful long-term weight loss maintenance. OBJECTIVE: This study aimed to provide insight into the design of eHealth interventions supporting behavior change for long-term weight maintenance. The study sought to identify the values and needs of people with obesity aiming to maintain weight after weight loss, and to identify PSD principles, BCTs, and design requirements that potentially enable an eHealth intervention to meet end user values and needs. METHODS: This study presents the concept of integrating PSD principles and BCTs into the design process of eHealth interventions to meet user values and needs. In this study, individual interviews and focus groups were conducted with people with obesity (n=23) and other key stakeholders (n=27) to explore end user values and needs related to weight loss maintenance. Design thinking methods were applied during the focus group sessions to identify design elements and to explore how eHealth solutions can support the needs to achieve sustainable weight loss maintenance. The PSD model and behavior change taxonomy by Michie were used to identify PSD principles and BCT clusters to meet end user values and needs. RESULTS: A total of 8 key end user values were identified, reflecting user needs for weight loss maintenance support: self-management, personalized care, autonomy, feel supported, positive self-image, motivation, happiness, and health. Goals and planning, feedback and monitoring, repetition and substitution, shaping knowledge, social support, identity, and self-belief were some of the BCT clusters identified to address these concepts, together with PSD principles such as personalization, tailoring, self-monitoring, praise, and suggestions. CONCLUSIONS: The process of translating end user values and needs into design elements or features of eHealth technologies is an important part of the design process. To our knowledge, this is the first study to explore how PSD principles and BCTs can be integrated when designing eHealth self-management interventions for long-term weight loss maintenance. End users and other key stakeholders highlighted important factors to be considered in the design of eHealth interventions supporting sustained behavior change. The PSD principles and BCTs identified provide insights and suggestions about design elements and features to include for supporting weight loss maintenance. The findings indicate that a combination of BCTs and PSD principles may be needed in evidence-based eHealth interventions to stimulate motivation and adherence to support healthy behaviors and sustained weight loss maintenance. TRIAL REGISTRATION: ClinicalTrials.gov NCT04537988; https://clinicaltrials.gov/ct2/show/NCT04537988.
