Rabanser Simon, Neumann Lukas, Haltmeier Markus
Department of Mathematics, University of Innsbruck, Technikerstraße 13, A-6020 Innsbruck, Austria.
Institute of Basic Sciences in Engineering Science, University of Innsbruck, Technikerstraße 13, A-6020 Innsbruck, Austria.
Entropy (Basel). 2018 Feb 11;20(2):121. doi: 10.3390/e20020121.
The development of accurate and efficient image reconstruction algorithms is a central aspect of quantitative photoacoustic tomography (QPAT). In this paper, we address this issues for multi-source QPAT using the radiative transfer equation (RTE) as accurate model for light transport. The tissue parameters are jointly reconstructed from the acoustical data measured for each of the applied sources. We develop stochastic proximal gradient methods for multi-source QPAT, which are more efficient than standard proximal gradient methods in which a single iterative update has complexity proportional to the number applies sources. Additionally, we introduce a completely new formulation of QPAT as multilinear (MULL) inverse problem which avoids explicitly solving the RTE. The MULL formulation of QPAT is again addressed with stochastic proximal gradient methods. Numerical results for both approaches are presented. Besides the introduction of stochastic proximal gradient algorithms to QPAT, we consider the new MULL formulation of QPAT as main contribution of this paper.
开发准确高效的图像重建算法是定量光声断层扫描(QPAT)的核心内容。在本文中,我们针对多源QPAT解决这一问题,使用辐射传输方程(RTE)作为光传输的精确模型。组织参数从针对每个应用源测量的声学数据中联合重建。我们为多源QPAT开发了随机近端梯度方法,该方法比标准近端梯度方法更有效,在标准近端梯度方法中,单个迭代更新的复杂度与应用源的数量成正比。此外,我们将QPAT全新地表述为多线性(MULL)逆问题,从而避免显式求解RTE。QPAT的MULL表述同样通过随机近端梯度方法来解决。给出了两种方法的数值结果。除了将随机近端梯度算法引入QPAT外,我们将QPAT的新MULL表述视为本文的主要贡献。
