Department of Orthopaedic Surgery and Joint Surgery Centre, Takatsuki General Hospital, Takatsuki, Japan.
Clin Orthop Surg. 2020 Dec;12(4):554-557. doi: 10.4055/cios20191. Epub 2020 Nov 18.
To reduce the stress on the medial tibial cortex and to decrease the risk of fracture, a varus cut of the tibia appears to be a reasonable alternative to the orthogonal cut by conventional methods. We present a new instrument and procedure, which enables a varus tibial cut for Oxford unicompartmental knee arthroplasty. We used a custom-made, slidable fixator instead of the standard fixator to set the extramedullary rod on the leg. We also made a numeric formula and a chart to arrange the varus cutting angle using the length of the mediolateral shift of the distal end and the longitudinal extension length of the extramedullary tibial rod. A varus cut up to 4.5° can be controlled. This technique is a simple and useful means of obtaining a varus tibial cut for Oxford unicompartmental knee arthroplasty.
为了减轻胫骨内侧皮质的压力,降低骨折的风险,胫骨的内翻截骨似乎是传统方法正交截骨的合理替代方法。我们介绍了一种新的器械和手术方法,可用于牛津单髁膝关节置换的胫骨内翻截骨。我们使用了一种定制的、可滑动的固定器来代替标准固定器,以将髓外杆固定在腿上。我们还制定了一个数值公式和图表,以便使用远端的内外侧移位长度和髓外胫骨杆的纵向延伸长度来安排内翻截骨角度。可以控制 4.5°以内的内翻角度。这种技术是获得牛津单髁膝关节置换胫骨内翻截骨的一种简单而有用的方法。
