Sugimoto Kozo, Matsuo Shigeki, Naoi Yoshiki
Department of Mechanical Engineering, Shibaura Institute of Technology, Toyosu, Koto-ku, Tokyo, 135-8548, Japan.
Graduate School of Technology, Industrial and Social Science, Tokushima University, Tokushima, 770-8506, Japan.
Sci Rep. 2020 Dec 8;10(1):21451. doi: 10.1038/s41598-020-78564-z.
Using focused subnanosecond laser pulses at [Formula: see text] wavelength, modification of silicon into opaque state was induced. While silicon exhibits one-photon absorption at this wavelength, the modification was induced inside [Formula: see text]-thick silicon substrate without damaging top or bottom surfaces. The depth range of the focus position was investigated where inside of the substrate can be modified without damaging the surfaces. Using this technique, diffraction gratings were inscribed inside silicon substrate. Diffraction from the gratings were observed, and the diffraction angle well agreed with the theoretical value. These results demonstrate that this technique could be used for fabricating infrared optical elements in silicon.
使用波长为[公式:见正文]的聚焦亚纳秒激光脉冲,可诱导硅转变为不透明状态。虽然硅在此波长下表现出单光子吸收,但这种转变是在厚度为[公式:见正文]的硅衬底内部诱导产生的,而不会损坏其顶面或底面。研究了聚焦位置的深度范围,在此范围内可以在不损坏表面的情况下对衬底内部进行改性。利用该技术,在硅衬底内部刻写了衍射光栅。观察到了光栅的衍射现象,衍射角与理论值吻合良好。这些结果表明,该技术可用于在硅中制造红外光学元件。
