一种用于无损监测植物中水和干物质含量的便携式核磁共振传感器及弛豫测量方法。

A Mobile NMR Sensor and Relaxometric Method to Non-destructively Monitor Water and Dry Matter Content in Plants.

作者信息

Windt Carel W, Nabel Moritz, Kochs Johannes, Jahnke Siegfried, Schurr Ulrich

机构信息

Institute for Bio- and Geosciences IBG-2: Plant Sciences, Forschungszentrum Jülich, Jülich, Germany.

Faculty of Biology Biodiversity, University of Duisburg-Essen, Essen, Germany.

出版信息

Front Plant Sci. 2021 Feb 5;12:617768. doi: 10.3389/fpls.2021.617768. eCollection 2021.

Abstract

Water content (WC) and dry matter content (DMC) are some of the most basic parameters to describe plant growth and yield, but are exceptionally difficult to measure non-invasively. Nuclear Magnetic Resonance (NMR) relaxometry may fill this methodological gap. It allows non-invasive detection of protons in liquids and solids, and on the basis of these measures, can be used to quantify liquid and dry matter contents of seeds and plants. Unfortunately, most existing NMR relaxometers are large, unwieldy and not suitable to measure intact plants or to be used under field conditions. In addition, currently the appropriate NMR relaxometric methods are poorly suited for non-expert use. We here present a novel approach to overcome these drawbacks. We demonstrate that a basic NMR relaxometer with the capability to accept intact plants, in combination with straightforward NMR and data processing methods, can be used as an NMR plant sensor to continuously, quantitatively and non-invasively monitor changes in WC and DMC. This can be done , and with high temporal resolution. The method is validated by showing that measured liquid and solid proton densities accurately reflect WC and DMC of reference samples. The NMR plant sensor is demonstrated in an experimental context by monitoring WC of rice leaves under osmotic stress, and by measuring the dynamics of water and dry matter accumulation during seed filling in a developing wheat ear. It is further demonstrated how the method can be used to estimate leaf water potential on the basis of changes in leaf water content.

摘要

水分含量(WC)和干物质含量(DMC)是描述植物生长和产量的一些最基本参数,但非侵入性测量异常困难。核磁共振(NMR)弛豫测量法可能填补这一方法学空白。它能够非侵入性地检测液体和固体中的质子,并基于这些测量结果,可用于量化种子和植物的液体和干物质含量。不幸的是,现有的大多数NMR弛豫仪体积庞大、操作不便,不适用于测量完整植株或在田间条件下使用。此外,目前合适的NMR弛豫测量方法不太适合非专业人员使用。我们在此提出一种新颖的方法来克服这些缺点。我们证明,一种能够容纳完整植株的基本NMR弛豫仪,结合简单的NMR和数据处理方法,可用作NMR植物传感器,以连续、定量和非侵入性地监测WC和DMC的变化。这可以做到,并且具有高时间分辨率。通过表明测量的液体和固体质子密度准确反映参考样品的WC和DMC,验证了该方法。通过监测渗透胁迫下水稻叶片的WC,以及测量发育中小麦穗灌浆期间水分和干物质积累的动态,在实验环境中展示了NMR植物传感器。进一步证明了该方法如何基于叶片含水量的变化来估计叶片水势。
