Feedforward Artificial Neural Network-Based Colorectal Cancer Detection Using Hyperspectral Imaging: A Step towards Automatic Optical Biopsy.

作者信息

Jansen-Winkeln Boris, Barberio Manuel, Chalopin Claire, Schierle Katrin, Diana Michele, Köhler Hannes, Gockel Ines, Maktabi Marianne

机构信息

Department of Visceral, Transplant, Thoracic and Vascular Surgery, University Hospital of Leipzig, 04103 Leipzig, Germany.

Institute for Research against Digestive Cancer (IRCAD), 67091 Strasbourg, France.

出版信息

Cancers (Basel). 2021 Feb 25;13(5):967. doi: 10.3390/cancers13050967.


DOI:10.3390/cancers13050967
PMID:33669082
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC7956537/
Abstract

Currently, colorectal cancer (CRC) is mainly identified via a visual assessment during colonoscopy, increasingly used artificial intelligence algorithms, or surgery. Subsequently, CRC is confirmed through a histopathological examination by a pathologist. Hyperspectral imaging (HSI), a non-invasive optical imaging technology, has shown promising results in the medical field. In the current study, we combined HSI with several artificial intelligence algorithms to discriminate CRC. Between July 2019 and May 2020, 54 consecutive patients undergoing colorectal resections for CRC were included. The tumor was imaged from the mucosal side with a hyperspectral camera. The image annotations were classified into three groups (cancer, CA; adenomatous margin around the central tumor, AD; and healthy mucosa, HM). Classification and visualization were performed based on a four-layer perceptron neural network. Based on a neural network, the classification of CA or AD resulted in a sensitivity of 86% and a specificity of 95%, by means of leave-one-patient-out cross-validation. Additionally, significant differences in terms of perfusion parameters (e.g., oxygen saturation) related to tumor staging and neoadjuvant therapy were observed. Hyperspectral imaging combined with automatic classification can be used to differentiate between CRC and healthy mucosa. Additionally, the biological changes induced by chemotherapy to the tissue are detectable with HSI.

摘要
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e779/7956537/16e475cd7353/cancers-13-00967-g005.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e779/7956537/22e1e829ce55/cancers-13-00967-g001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e779/7956537/4a452b6f284f/cancers-13-00967-g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e779/7956537/6c9129fdd750/cancers-13-00967-g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e779/7956537/b0b5a9e3f861/cancers-13-00967-g004.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e779/7956537/16e475cd7353/cancers-13-00967-g005.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e779/7956537/22e1e829ce55/cancers-13-00967-g001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e779/7956537/4a452b6f284f/cancers-13-00967-g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e779/7956537/6c9129fdd750/cancers-13-00967-g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e779/7956537/b0b5a9e3f861/cancers-13-00967-g004.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/e779/7956537/16e475cd7353/cancers-13-00967-g005.jpg
