Schlesinger Itai, Powers-Riggs Natalia E, Logsdon Jenna L, Qi Yue, Miller Stephen A, Tempelaar Roel, Young Ryan M, Wasielewski Michael R
Department of Chemistry and Institute for Sustainability and Energy at Northwestern, Northwestern University 2145 Sheridan Road Evanston Illinois 60208-3113 USA
Chem Sci. 2020 Aug 13;11(35):9532-9541. doi: 10.1039/d0sc03301d.
Organic donor-acceptor (D-A) co-crystals have attracted much interest due to their important optical and electronic properties. Co-crystals having ⋯DADA⋯ π-stacked morphologies are especially interesting because photoexcitation produces a charge-transfer (CT) exciton, D˙-A˙, between adjacent D-A molecules. Although several studies have reported on the steady-state optical properties of this type of CT exciton, very few have measured the dynamics of its formation and decay in a single D-A co-crystal. We have co-crystallized a -xanthenoxanthene () donor with a ,-bis(3-pentyl)-2,5,8,11-tetraphenylperylene-3,4:9,10-bis(dicarboximide) () acceptor to give an orthorhombic - ⋯DADA⋯ π-stacked co-crystal with a CT transition dipole moment that is perpendicular to the transition moments for S ← S excitation of and . Using polarized, broadband, femtosecond pump-probe microscopy, we have determined that selective photoexcitation of in the single co-crystal results in CT exciton formation within the 300 fs instrument response time. At early times (0.3 ≤ ≤ 500 ps), the CT excitons decay with a dependence, which is attributed to CT biexciton annihilation within the one-dimensional ⋯DADA⋯ π-stacks producing high-energy, long-lived (>8 ns) electron-hole pairs in the crystal. These energetic charge carriers may prove useful in applications ranging from photovoltaics and opto-electronics to photocatalysis.
有机供体 - 受体(D - A)共晶体因其重要的光学和电子性质而备受关注。具有⋯DADA⋯π堆积形态的共晶体尤其有趣,因为光激发会在相邻的D - A分子之间产生电荷转移(CT)激子,即D˙ - A˙。尽管已有多项研究报道了这类CT激子的稳态光学性质,但很少有研究测量其在单个D - A共晶体中形成和衰变的动力学过程。我们将一种呫吨酮()供体与一种1,7 - 双(3 - 戊基) - 2,5,8,11 - 四苯基苝 - 3,4:9,10 - 双(二甲酰亚胺)()受体共结晶,得到一种正交晶系的 - ⋯DADA⋯π堆积共晶体,其CT跃迁偶极矩垂直于和的S←S激发的跃迁矩。使用偏振、宽带、飞秒泵浦 - 探测显微镜,我们确定在单个共晶体中对进行选择性光激发会在300 fs的仪器响应时间内导致CT激子形成。在早期(0.3≤≤500 ps),CT激子以依赖关系衰变,这归因于一维⋯DADA⋯π堆积内的CT双激子湮灭,在晶体中产生高能、长寿命(>8 ns)的电子 - 空穴对。这些高能电荷载流子在从光伏、光电子到光催化等一系列应用中可能会很有用。
