Moeglin Eric, Desplancq Dominique, Stoessel Audrey, Massute Christian, Ranniger Jeremy, McEwen Alastair G, Zeder-Lutz Gabrielle, Oulad-Abdelghani Mustapha, Chiper Manuela, Lafaye Pierre, Di Ventura Barbara, Didier Pascal, Poterszman Arnaud, Weiss Etienne
Biotechnologie et Signalisation Cellulaire, UMR 7242, CNRS/Université de Strasbourg, Boulevard S. Brant, 67412 Illkirch, France.
Signaling Research Centers BIOSS and CIBSS and Institute of Biology II, University of Freiburg, Schänzlestrasse 1, 79104 Freiburg, Germany.
Cancers (Basel). 2021 Jul 1;13(13):3317. doi: 10.3390/cancers13133317.
Histone H2AX phosphorylated at serine 139 (γ-H2AX) is a hallmark of DNA damage, signaling the presence of DNA double-strand breaks and global replication stress in mammalian cells. While γ-H2AX can be visualized with antibodies in fixed cells, its detection in living cells was so far not possible. Here, we used immune libraries and phage display to isolate nanobodies that specifically bind to γ-H2AX. We solved the crystal structure of the most soluble nanobody in complex with the phosphopeptide corresponding to the C-terminus of γ-H2AX and show the atomic constituents behind its specificity. We engineered a bivalent version of this nanobody and show that bivalency is essential to quantitatively visualize γ-H2AX in fixed drug-treated cells. After labelling with a chemical fluorophore, we were able to detect γ-H2AX in a single-step assay with the same sensitivity as with validated antibodies. Moreover, we produced fluorescent nanobody-dTomato fusion proteins and applied a transduction strategy to visualize with precision γ-H2AX foci present in intact living cells following drug treatment. Together, this novel tool allows performing fast screenings of genotoxic drugs and enables to study the dynamics of this particular chromatin modification in individual cancer cells under a variety of conditions.
在丝氨酸139位点磷酸化的组蛋白H2AX(γ-H2AX)是DNA损伤的标志,表明哺乳动物细胞中存在DNA双链断裂和整体复制应激。虽然γ-H2AX可以在固定细胞中用抗体可视化,但迄今为止在活细胞中检测它是不可能的。在这里,我们使用免疫文库和噬菌体展示来分离特异性结合γ-H2AX的纳米抗体。我们解析了最易溶的纳米抗体与对应于γ-H2AX C末端的磷酸肽复合物的晶体结构,并展示了其特异性背后的原子组成。我们设计了这种纳米抗体的二价形式,并表明二价对于在固定的药物处理细胞中定量可视化γ-H2AX至关重要。在用化学荧光团标记后,我们能够在单步检测中以与经过验证的抗体相同的灵敏度检测γ-H2AX。此外,我们生产了荧光纳米抗体-dTomato融合蛋白,并应用转导策略精确可视化药物处理后完整活细胞中存在的γ-H2AX焦点。总之,这种新型工具允许对遗传毒性药物进行快速筛选,并能够在各种条件下研究单个癌细胞中这种特定染色质修饰的动态变化。
