Department of Radiology, University Hospital, LMU Munich, Marchioninistraße 15, 81377, Munich, Germany.
Radiologie München, Burgstraße 7, 80331, Munich, Germany.
Eur Radiol. 2022 Jul;32(7):4749-4759. doi: 10.1007/s00330-021-08532-2. Epub 2022 Jan 26.
OBJECTIVES: To investigate the differentiation of premalignant from benign colorectal polyps detected by CT colonography using deep learning. METHODS: In this retrospective analysis of an average risk colorectal cancer screening sample, polyps of all size categories and morphologies were manually segmented on supine and prone CT colonography images and classified as premalignant (adenoma) or benign (hyperplastic polyp or regular mucosa) according to histopathology. Two deep learning models SEG and noSEG were trained on 3D CT colonography image subvolumes to predict polyp class, and model SEG was additionally trained with polyp segmentation masks. Diagnostic performance was validated in an independent external multicentre test sample. Predictions were analysed with the visualisation technique Grad-CAM++. RESULTS: The training set consisted of 107 colorectal polyps in 63 patients (mean age: 63 ± 8 years, 40 men) comprising 169 polyp segmentations. The external test set included 77 polyps in 59 patients comprising 118 polyp segmentations. Model SEG achieved a ROC-AUC of 0.83 and 80% sensitivity at 69% specificity for differentiating premalignant from benign polyps. Model noSEG yielded a ROC-AUC of 0.75, 80% sensitivity at 44% specificity, and an average Grad-CAM++ heatmap score of ≥ 0.25 in 90% of polyp tissue. CONCLUSIONS: In this proof-of-concept study, deep learning enabled the differentiation of premalignant from benign colorectal polyps detected with CT colonography and the visualisation of image regions important for predictions. The approach did not require polyp segmentation and thus has the potential to facilitate the identification of high-risk polyps as an automated second reader. KEY POINTS: • Non-invasive deep learning image analysis may differentiate premalignant from benign colorectal polyps found in CT colonography scans. • Deep learning autonomously learned to focus on polyp tissue for predictions without the need for prior polyp segmentation by experts. • Deep learning potentially improves the diagnostic accuracy of CT colonography in colorectal cancer screening by allowing for a more precise selection of patients who would benefit from endoscopic polypectomy, especially for patients with polyps of 6-9 mm size.
目的:利用深度学习技术探究 CT 结肠成像检测到的癌前与良性结直肠息肉的区别。
方法:本回顾性分析纳入了平均风险结直肠癌筛查样本,对仰卧位和俯卧位 CT 结肠成像图像上所有大小和形态的息肉进行手动分割,并根据组织病理学将其归类为癌前(腺瘤)或良性(增生性息肉或正常黏膜)。将两个深度学习模型 SEG 和 noSEG 应用于 3D CT 结肠成像图像子体积,以预测息肉类别,模型 SEG 还可以使用息肉分割掩模进行训练。在独立的外部多中心测试样本中验证诊断性能。使用可视化技术 Grad-CAM++ 分析预测结果。
结果:训练集包含 63 名患者(平均年龄 63±8 岁,40 名男性)中的 107 个结直肠息肉,共 169 个息肉分割。外部测试集包含 59 名患者中的 77 个息肉,共 118 个息肉分割。模型 SEG 在区分癌前与良性息肉方面的 ROC-AUC 为 0.83,敏感度为 80%,特异性为 69%。模型 noSEG 的 ROC-AUC 为 0.75,敏感度为 80%,特异性为 44%,在 90%的息肉组织中平均 Grad-CAM++热图评分≥0.25。
结论:在这项概念验证研究中,深度学习实现了 CT 结肠成像检测到的癌前与良性结直肠息肉的区分,并对预测中重要的图像区域进行了可视化。该方法不需要息肉分割,因此有可能作为自动的第二读者来帮助识别高危息肉。
关键点:
