乳腺超快速动态对比增强 MRI:如何使用?

Ultrafast Dynamic Contrast-enhanced MRI of the Breast: How Is It Used?

机构信息

Department of Diagnostic Imaging and Nuclear Medicine, Kyoto University Graduate School of Medicine.

Department of Diagnostic Radiology, Kansai Electric Power Hospital.

出版信息

Magn Reson Med Sci. 2022 Mar 1;21(1):83-94. doi: 10.2463/mrms.rev.2021-0157. Epub 2022 Feb 25.

Abstract

Ultrafast dynamic contrast-enhanced (UF-DCE) MRI is a new approach to capture kinetic information in the very early post-contrast period with high temporal resolution while keeping reasonable spatial resolution. The detailed timing and shape of the upslope in the time-intensity curve are analyzed. New kinetic parameters obtained from UF-DCE MRI are useful in differentiating malignant from benign lesions and in evaluating prognostic markers of the breast cancers. Clinically, UF-DCE MRI contributes in identifying hypervascular lesions when the background parenchymal enhancement (BPE) is marked on conventional dynamic MRI. This review starts with the technical aspect of accelerated acquisition. Practical aspects of UF-DCE MRI include identification of target hypervascular lesions from marked BPE and diagnosis of malignant and benign lesions based on new kinetic parameters derived from UF-DCE MRI: maximum slope (MS), time to enhance (TTE), bolus arrival time (BAT), time interval between arterial and venous visualization (AVI), and empirical mathematical model (EMM). The parameters derived from UF-DCE MRI are compared in terms of their diagnostic performance and association with prognostic markers. Pitfalls of UF-DCE MRI in the clinical situation are also covered. Since UF-DCE MRI is an evolving technique, future prospects of UF-DCE MRI are discussed in detail by citing recent evidence. The topic covers prediction of treatment response, multiparametric approach using DWI-derived parameters, evaluation of tumor-related vessels, and application of artificial intelligence for UF-DCE MRI. Along with comprehensive literature review, illustrative clinical cases are used to understand the value of UF-DCE MRI.

摘要

超快速动态对比增强(UF-DCE)MRI 是一种新方法,可在保持合理空间分辨率的同时,以高时间分辨率捕获对比后早期的动力学信息。分析时间-强度曲线上升支的详细定时和形状。从 UF-DCE MRI 获得的新动力学参数可用于区分良恶性病变,并评估乳腺癌的预后标志物。在常规动态 MRI 上标记背景实质强化(BPE)时,UF-DCE MRI 有助于识别富血管病变。本文从加速采集的技术方面开始介绍。UF-DCE MRI 的实际应用包括从标记的 BPE 中识别目标富血管病变,以及基于从 UF-DCE MRI 获得的新动力学参数诊断恶性和良性病变:最大斜率(MS)、增强时间(TTE)、造影剂到达时间(BAT)、动脉和静脉可视化之间的时间间隔(AVI)和经验数学模型(EMM)。比较了 UF-DCE MRI 衍生参数的诊断性能及其与预后标志物的相关性。还涵盖了 UF-DCE MRI 在临床情况下的缺陷。由于 UF-DCE MRI 是一种不断发展的技术,因此通过引用最新证据详细讨论了 UF-DCE MRI 的未来前景。该主题涵盖了治疗反应的预测、使用 DWI 衍生参数的多参数方法、肿瘤相关血管的评估以及人工智能在 UF-DCE MRI 中的应用。除了全面的文献综述外,还使用说明性临床病例来了解 UF-DCE MRI 的价值。
