Zhou Weimin, Bhadra Sayantan, Brooks Frank J, Li Hua, Anastasio Mark A
University of California Santa Barbara, Department of Psychological and Brain Sciences, Santa Barbara, California, United States.
Washington University in St. Louis, Department of Computer Science and Engineering, St. Louis, Missouri, United States.
J Med Imaging (Bellingham). 2022 Jan;9(1):015503. doi: 10.1117/1.JMI.9.1.015503. Epub 2022 Feb 23.
To objectively assess new medical imaging technologies via computer-simulations, it is important to account for the variability in the ensemble of objects to be imaged. This source of variability can be described by stochastic object models (SOMs). It is generally desirable to establish SOMs from experimental imaging measurements acquired by use of a well-characterized imaging system, but this task has remained challenging. A generative adversarial network (GAN)-based method that employs AmbientGANs with modern progressive or multiresolution training approaches is proposed. AmbientGANs established using the proposed training procedure are systematically validated in a controlled way using computer-simulated magnetic resonance imaging (MRI) data corresponding to a stylized imaging system. Emulated single-coil experimental MRI data are also employed to demonstrate the methods under less stylized conditions. The proposed AmbientGAN method can generate clean images when the imaging measurements are contaminated by measurement noise. When the imaging measurement data are incomplete, the proposed AmbientGAN can reliably learn the distribution of the measurement components of the objects. Both visual examinations and quantitative analyses, including task-specific validations using the Hotelling observer, demonstrated that the proposed AmbientGAN method holds promise to establish realistic SOMs from imaging measurements.
为了通过计算机模拟客观评估新的医学成像技术,考虑待成像物体集合中的变异性很重要。这种变异性来源可以用随机物体模型(SOM)来描述。通常希望从使用特征明确的成像系统获取的实验成像测量中建立SOM,但这项任务仍然具有挑战性。提出了一种基于生成对抗网络(GAN)的方法,该方法采用具有现代渐进式或多分辨率训练方法的环境GAN。使用所提出的训练过程建立的环境GAN使用对应于程式化成像系统的计算机模拟磁共振成像(MRI)数据以可控方式进行系统验证。还采用模拟的单线圈实验MRI数据来证明该方法在不太程式化的条件下的有效性。当成像测量受到测量噪声污染时,所提出的环境GAN方法可以生成清晰的图像。当成像测量数据不完整时,所提出的环境GAN可以可靠地学习物体测量分量的分布。视觉检查和定量分析,包括使用霍特林观察者进行的特定任务验证,都表明所提出的环境GAN方法有望从成像测量中建立逼真的SOM。
