Wu Hao, Zhang Hantao, Wang Baomin, Groß Felix, Yang Chao-Yao, Li Gengfei, Guo Chenyang, He Haoran, Wong Kin, Wu Di, Han Xiufeng, Lai Chih-Huang, Gräfe Joachim, Cheng Ran, Wang Kang L
Department of Electrical and Computer Engineering, University of California, Los Angeles, CA, 90095, USA.
Songshan Lake Materials Laboratory, Dongguan, Guangdong, 523808, China.
Nat Commun. 2022 Mar 28;13(1):1629. doi: 10.1038/s41467-022-29170-2.
Terahertz (THz) spin dynamics and vanishing stray field make antiferromagnetic (AFM) materials the most promising candidate for the next-generation magnetic memory technology with revolutionary storage density and writing speed. However, owing to the extremely large exchange energy barriers, energy-efficient manipulation has been a fundamental challenge in AFM systems. Here, we report an electrical writing of antiferromagnetic orders through a record-low current density on the order of 10 A cm facilitated by the unique AFM-ferromagnetic (FM) phase transition in FeRh. By introducing a transient FM state via current-induced Joule heating, the spin-orbit torque can switch the AFM order parameter by 90° with a reduced writing current density similar to ordinary FM materials. This mechanism is further verified by measuring the temperature and magnetic bias field dependences, where the X-ray magnetic linear dichroism (XMLD) results confirm the AFM switching besides the electrical transport measurement. Our findings demonstrate the exciting possibility of writing operations in AFM-based devices with a lower current density, opening a new pathway towards pure AFM memory applications.
太赫兹(THz)自旋动力学和零杂散场使反铁磁(AFM)材料成为下一代磁存储技术最有前景的候选材料,具有革命性的存储密度和写入速度。然而,由于存在极大的交换能垒,能量高效操控一直是AFM系统面临的一项基本挑战。在此,我们报告了通过FeRh中独特的反铁磁 - 铁磁(FM)相变,以创纪录的低电流密度(约10 A/cm²)实现反铁磁序的电写入。通过电流诱导的焦耳热引入瞬态FM态,自旋轨道转矩能够以类似于普通FM材料的降低的写入电流密度将AFM序参量切换90°。通过测量温度和磁偏置场依赖性进一步验证了这一机制,其中除了电输运测量外,X射线磁线性二色性(XMLD)结果证实了AFM切换。我们的研究结果证明了以较低电流密度在基于AFM的器件中进行写入操作的令人兴奋的可能性,为纯AFM存储应用开辟了一条新途径。
