用于高性能超级电容器的均匀海胆状氮掺杂NiCoO@C中空纳米结构的制备

Fabrication of uniform urchin-like N-doped NiCoO@C hollow nanostructures for high performance supercapacitors.

作者信息

Hu XiaoYu, Huang MiaoFeng, Meng XianHe, Ju Xin

机构信息

School of Mathematics and Physics, University of Science and Technology Beijing Beijing 100083 China

College of Materials and Chemistry, China Jiliang University Hangzhou 310018 China.

出版信息

RSC Adv. 2019 Dec 19;9(72):42110-42119. doi: 10.1039/c9ra07678f. eCollection 2019 Dec 18.

Abstract

Transition metal oxides are commonly used in electrochemical energy storage materials, but there are still many drawbacks that impede a wide range of applications. Heteroatom doping can significantly improve its performance. Herein, we have successfully prepared highly uniform N-doped NiCoO@C hollow nanostructures for supercapacitors by a two-step hydrothermal treatment associated with successive annealing process. Prepared N-doped NiCoO@C materials exhibited an admirable specific capacitance of 1028 F g at a current density of 3 A g, with 625 F g remaining even at high current density of 20 A g. Besides, this composite showed good electrochemical stability with capacity retention of 84% after 5000 cycles repetitive galvanostatic charge-discharge test at 10 A g. An asymmetric supercapacitor was assembled by the N-doped NiCoO@C electrode, attached activate carbon (AC) as a counter electrode, exhibiting a high energy density of 26.67 W h kg at a power density of 402 W kg. The improvement of electrochemical performance is ascribed to the co-doping of nitrogen and carbon atoms. These results indicate that N-doped NiCoO@C can be employed as an ideal electrode material for electrochemical energy storage.

摘要

过渡金属氧化物常用于电化学储能材料,但仍存在许多阻碍其广泛应用的缺点。杂原子掺杂可以显著提高其性能。在此,我们通过两步水热处理结合连续退火工艺,成功制备了用于超级电容器的高度均匀的氮掺杂NiCoO@C中空纳米结构。制备的氮掺杂NiCoO@C材料在电流密度为3 A g时表现出令人钦佩的1028 F g的比电容,即使在20 A g的高电流密度下仍有625 F g。此外,该复合材料在10 A g下进行5000次循环恒流充放电测试后,表现出良好的电化学稳定性,容量保持率为84%。以氮掺杂NiCoO@C电极为正极,活性炭(AC)为负极组装了不对称超级电容器,在功率密度为402 W kg时表现出26.67 W h kg的高能量密度。电化学性能的提高归因于氮和碳原子的共掺杂。这些结果表明,氮掺杂NiCoO@C可作为电化学储能的理想电极材料。
