用于低频磁电设备的复合材料物理学

Physics of Composites for Low-Frequency Magnetoelectric Devices.

作者信息

Bichurin Mirza, Sokolov Oleg, Ivanov Sergey, Leontiev Viktor, Petrov Dmitriy, Semenov Gennady, Lobekin Vyacheslav

机构信息

Yaroslav-the-Wise Novgorod State University, 173003 Veliky Novgorod, Russia.

出版信息

Sensors (Basel). 2022 Jun 25;22(13):4818. doi: 10.3390/s22134818.

DOI:10.3390/s22134818
PMID:35808313
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC9269355/
Abstract

The article discusses the physical foundations of the application of the linear magnetoelectric (ME) effect in composites for devices in the low-frequency range, including the electromechanical resonance (EMR) region. The main theoretical expressions for the ME voltage coefficients in the case of a symmetric and asymmetric composite structure in the quasi-static and resonant modes are given. The area of EMR considered here includes longitudinal, bending, longitudinal shear, and torsional modes. Explanations are given for finding the main resonant frequencies of the modes under study. Comparison of theory and experimental results for some composites is given.

摘要

本文讨论了线性磁电（ME）效应在低频范围内用于器件的复合材料中的应用的物理基础，包括机电共振（EMR）区域。给出了准静态和谐振模式下对称和不对称复合结构情况下ME电压系数的主要理论表达式。这里考虑的EMR区域包括纵向、弯曲、纵向剪切和扭转模式。对确定所研究模式的主要共振频率进行了解释。给出了一些复合材料的理论与实验结果的比较。
