Han Xiaoyu, Fan Jun, Zheng Yuting, Ding Chengyu, Zhang Xiaohui, Zhang Kailu, Wang Na, Jia Xi, Li Yumin, Liu Jia, Zheng Jinlong, Shi Heshui
Department of Radiology, Union Hospital, Tongji Medical College, Huazhong University of Science and Technology, Wuhan, China.
Hubei Province Key Laboratory of Molecular Imaging, Wuhan, China.
Front Oncol. 2022 Jul 8;12:757389. doi: 10.3389/fonc.2022.757389. eCollection 2022.
Spread through air spaces (STAS), a new invasive pattern in lung adenocarcinoma (LUAD), is a risk factor for poor outcome in early-stage LUAD. This study aimed to develop and validate a CT-based radiomics model for predicting STAS in stage IA LUAD.
A total of 395 patients (169 STAS positive and 226 STAS negative cases, including 316 and 79 patients in the training and test sets, respectively) with stage IA LUAD before surgery were retrospectively included. On all CT images, tumor size, types of nodules (solid, mix ground-glass opacities [mGGO] and pure GGO [pGGO]), and GGO percentage were recorded. Region of interest (ROI) segmentation was performed semi-automatically, and 1,037 radiomics features were extracted from every segmented lesion. Intraclass correlation coefficients (ICCs), Pearson's correlation analysis and least absolute shrinkage and selection operator (LASSO) penalized logistic regression were used to filter unstable (ICC < 0.75) and redundant features (r > 0.8). A temporary model was established by multivariable logistic regression (LR) analysis based on selected radiomics features. Then, seven radiomics features contributing the most were selected for establishing the radiomics model. We then built two predictive models (clinical-CT model and MixModel) based on clinical and CT features only, and the combination of clinical-CT and Rad-score, respectively. The performances of these three models were assessed.
The radiomics model achieved good performance with an area under of curve (AUC) of 0.812 in the training set, versus 0.850 in the test set. Furthermore, compared with the clinical-CT model, both radiomics model and MixModel showed higher AUC and better net benefit to patients in the training and test cohorts.
The CT-based radiomics model showed satisfying diagnostic performance in early-stage LUAD for preoperatively predicting STAS, with superiority over the clinical-CT model.
气腔播散(STAS)是肺腺癌(LUAD)一种新的浸润模式,是早期LUAD预后不良的危险因素。本研究旨在开发并验证一种基于CT的放射组学模型,用于预测IA期LUAD中的STAS。
回顾性纳入395例术前IA期LUAD患者(169例STAS阳性和226例STAS阴性病例,训练集和测试集分别包括316例和79例患者)。在所有CT图像上,记录肿瘤大小、结节类型(实性、混合磨玻璃密度影[mGGO]和纯磨玻璃密度影[pGGO])以及GGO百分比。半自动进行感兴趣区(ROI)分割,并从每个分割病变中提取1037个放射组学特征。使用组内相关系数(ICC)、Pearson相关分析和最小绝对收缩和选择算子(LASSO)惩罚逻辑回归来筛选不稳定(ICC < 0.75)和冗余特征(r > 0.8)。基于选定的放射组学特征,通过多变量逻辑回归(LR)分析建立临时模型。然后,选择贡献最大的7个放射组学特征来建立放射组学模型。然后,我们分别基于临床和CT特征以及临床-CT和Rad评分的组合构建了两个预测模型(临床-CT模型和混合模型)。评估这三个模型的性能。
放射组学模型在训练集中的曲线下面积(AUC)为0.812,在测试集中为0.850,表现良好。此外,与临床-CT模型相比,放射组学模型和混合模型在训练和测试队列中均显示出更高的AUC和对患者更好的净效益。
基于CT的放射组学模型在早期LUAD术前预测STAS方面显示出令人满意的诊断性能,优于临床-CT模型。
