Kim Hoonsub, Im Pyung Won, Lee Chaedong, Hong Hwichan, Lee Wooseung, Koo Changhyuk, Park Sang Yoon, Im Hyung-Jun, Paek Sun Ha, Piao Yuanzhe
Department of Applied Bioengineering, Graduate School of Convergence Science and Technology, Seoul National University Suwon-si Gyeonggi-do 16229 Republic of Korea
Cancer Research Institute, Seoul National University Seoul 03080 Republic of Korea
RSC Adv. 2023 Jan 19;13(5):2803-2810. doi: 10.1039/d2ra07190h. eCollection 2023 Jan 18.
Currently, research on superparamagnetic iron oxide nanoparticles (SPIONs) for magnetic hyperthermia applications is steadily increasing. In this work, SPIONs were synthesized by the bromide-assisted polyol method and angle-shaped SPIONs were successfully generated with the optimized concentration of bromide. The influence of bromide concentration on the shape of the generated SPIONs as well as the heating characteristics under an alternating magnetic field (AMF) was thoroughly investigated. At a concentration of 20 mg mL of the angle-shaped SPIONs, the highest temperature curve up to 23 °C was observed under AMF with 140 Oe and 100 kHz for 10 min. With the biotoxicity assay, no significant cytotoxicity was observed in the normal fibroblast of HFB-141103 as well as tumor cells of U87MG and FSall treated with the angle-shaped SPIONs at a concentration below 100 μg mL. However, significantly decreased cellular viability was observed in tumor cells of U87MG and FSall treated with 100 μg mL of the angle-shaped SPIONs under AMF with 140 Oe and 100 kHz. Based on these results, it is thought that the angle-shaped SPIONs synthesized by the bromide-assisted polyol method will provide highly efficient magnetic hyperthermia therapy for cancers under biologically safe AMF with 140 Oe and 100 kHz.
目前,用于磁热疗的超顺磁性氧化铁纳米颗粒(SPIONs)的研究正在稳步增加。在这项工作中,通过溴化物辅助多元醇法合成了SPIONs,并通过优化溴化物浓度成功制备出角形SPIONs。深入研究了溴化物浓度对生成的SPIONs形状以及在交变磁场(AMF)下加热特性的影响。在角形SPIONs浓度为20 mg/mL时,在140 Oe和100 kHz的AMF下处理10分钟,观察到最高温度曲线达到23°C。通过生物毒性测定,在浓度低于100 μg/mL的角形SPIONs处理的HFB - 141103正常成纤维细胞以及U87MG和FSall肿瘤细胞中未观察到明显的细胞毒性。然而,在用100 μg/mL的角形SPIONs在140 Oe和100 kHz的AMF下处理的U87MG和FSall肿瘤细胞中,观察到细胞活力显著下降。基于这些结果,认为通过溴化物辅助多元醇法合成的角形SPIONs将在140 Oe和100 kHz的生物安全AMF下为癌症提供高效的磁热疗。
