Detection of Rice Fungal Spores Based on Micro- Hyperspectral and Microfluidic Techniques.

As rice is one of the world's most important food crops, protecting it from fungal diseases is very important for agricultural production. At present, it is difficult to diagnose rice fungal diseases at an early stage using relevant technologies, and there are a lack of rapid detection methods. This study proposes a microfluidic chip-based method combined with microscopic hyperspectral detection of rice fungal disease spores. First, a microfluidic chip with a dual inlet and three-stage structure was designed to separate and enrich spores and spores in air. Then, the microscopic hyperspectral instrument was used to collect the hyperspectral data of the fungal disease spores in the enrichment area, and the competitive adaptive reweighting algorithm (CARS) was used to screen the characteristic bands of the spectral data collected from the spores of the two fungal diseases. Finally, the support vector machine (SVM) and convolutional neural network (CNN) were used to build the full-band classification model and the CARS filtered characteristic wavelength classification model, respectively. The results showed that the actual enrichment efficiency of the microfluidic chip designed in this study on spores and spores was 82.67% and 80.70%, respectively. In the established model, the CARS-CNN classification model is the best for the classification of spores and spores, and its F1-core index can reach 0.960 and 0.949, respectively. This study can effectively isolate and enrich spores and spores, providing new methods and ideas for early detection of rice fungal disease spores.
