四种液质联用平台分析尿液中扎罗醇的比较
A comparison of four liquid chromatography-mass spectrometry platforms for the analysis of zeranols in urine.
机构信息
Environmental and Occupational Health Sciences Institute, Rutgers University, Piscataway, NJ, 08854, USA.
Department of Biostatistics and Epidemiology, Rutgers School of Public Health, Rutgers University, Piscataway, NJ, 08854, USA.
出版信息
Anal Bioanal Chem. 2023 Aug;415(20):4885-4899. doi: 10.1007/s00216-023-04791-8. Epub 2023 Jul 11.
Targeted biomonitoring studies quantifying the concentration of zeranols in biological matrices have focused on liquid chromatography interfaced to mass spectrometry (LC-MS). The MS platform for measurement, quadrupole, time-of-flight (ToF), ion trap, etc., is often chosen based on either sensitivity or selectivity. An instrument performance comparison of the benefits and limitations using matrix-matched standards containing 6 zeranols on 4 MS instruments, 2 low-resolution (linear ion traps), and 2 high-resolution (Orbitrap and ToF) was undertaken to identify the best measurement platform for multiple biomonitoring projects characterizing the endocrine disruptive properties of zeranols. Analytical figures of merit were calculated for each analyte to compare instrument performance across platforms. The calibration curves had correlation coefficients r = 0.989 ± 0.012 for all analytes and LODs and LOQs were ranked for sensitivity: Orbitrap > LTQ > LTQXL > G1 (V mode) > G1 (W mode). The Orbitrap had the smallest measured variation (lowest %CV), while the G1 had the highest. Instrumental selectivity was calculated using full width at half maximum (FWHM) and as expected, the low-resolution instruments had the broadest spectrometric peaks, concealing coeluting peaks under the same mass window as the analyte. Multiple peaks from concomitant ions, unresolved at low resolution (within a unit mass window), were present but did not match the exact mass predicted for the analyte. For example, the high-resolution platforms were able to differentiate between a concomitant peak at 319.1915 from the analyte at 319.1551, included in low-resolution quantitative analyses demonstrating the need to consider coeluting interfering ions in biomonitoring studies. Finally, a validated method using the Orbitrap was applied to human urine samples from a pilot cohort study.
靶向生物监测研究通过液相色谱-质谱(LC-MS)定量测定生物基质中泽兰醇的浓度。测量所采用的质谱平台(四极杆、飞行时间(ToF)、离子阱等)通常基于灵敏度或选择性来选择。本研究对使用包含 6 种泽兰醇的基质匹配标准品在 4 种 MS 仪器(2 种低分辨率(线性离子阱)和 2 种高分辨率(轨道阱和 ToF))上进行仪器性能比较,以确定最适合用于多个生物监测项目的测量平台,这些项目用于描述泽兰醇的内分泌干扰特性。为了比较不同平台上的仪器性能,对每个分析物计算了分析的质量指标。所有分析物的校准曲线相关系数 r 均为 0.989±0.012,并且根据灵敏度对 LOD 和 LOQ 进行了排序:轨道阱>LTQ>LTQXL>G1(V 模式)>G1(W 模式)。轨道阱的测量变化最小(最低%CV),而 G1 的则最大。仪器选择性使用半峰宽(FWHM)进行计算,并且正如预期的那样,低分辨率仪器的光谱峰最宽,在与分析物相同的质量窗口下隐藏了共洗脱峰。在低分辨率下(在一个单位质量窗口内)未解析的、伴随离子的多个峰存在,但与分析物的预测精确质量不匹配。例如,在高分辨率平台上能够区分分析物 319.1551 与 319.1915 处的伴随峰,这表明在生物监测研究中需要考虑共洗脱干扰离子。最后,应用经验证的轨道阱方法对来自试点队列研究的人尿液样本进行了分析。
