Principal component analysis on twenty years (2000-2020) of geochemical and geophysical observations at Campi Flegrei active caldera.

Campi Flegrei (CF) is an active and densely populated caldera in Southern Italy, which has manifested signs of significant unrest in the last 50 years. Due to the high volcanic risk, monitoring networks of the most sensitive unrest indicators have been implemented and improved over time. Precious database constituted by geophysical and geochemical data allowed the study of the caldera unrest phases. In this paper we retrace the caldera history in the time span 2000-2020 by analyzing displacement, seismicity and geochemical time series in a unified framework. To this end, Principal Component Analysis (PCA) was firstly applied only on geochemical data because of their compositional nature. The retrieved first three components were successively analyzed via PCA together with the geophysical and thermodynamical variables. Our results suggest that three independent processes relay on geochemical observations: a heating/pressurizing of the hydrothermal system, a process related to magmatic fluids injection at the hydrothermal system roots, and third process probably connected with a deeper magmatic dynamic. The actual volcano alert state seems mainly linked to the variation of the hydrothermal system activity. Our approach made it possible to explore the interrelation among observations of different nature highlighting the importance of the relative driving processes over time.
