A Method for the Spatial Interpolation of EEG Signals Based on the Bidirectional Long Short-Term Memory Network.

The precision of electroencephalograms (EEGs) significantly impacts the performance of brain-computer interfaces (BCI). Currently, the majority of research into BCI technology gives priority to lightweight design and a reduced electrode count to make it more suitable for application in wearable environments. This paper introduces a deep learning-based time series bidirectional (BiLSTM) network that is designed to capture the inherent characteristics of EEG channels obtained from neighboring electrodes. It aims to predict the EEG data time series and facilitate the conversion process from low-density EEG signals to high-density EEG signals. BiLSTM pays more attention to the dependencies in time series data rather than mathematical maps, and the root mean square error can be effectively restricted to below 0.4μV, which is less than half the error in traditional methods. After expanding the BCI Competition III 3a dataset from 18 channels to 60 channels, we conducted classification experiments on four types of motor imagery tasks. Compared to the original low-density EEG signals (18 channels), the classification accuracy was around 82%, an increase of about 20%. When juxtaposed with real high-density signals, the increment in the error rate remained below 5%. The expansion of the EEG channels showed a substantial and notable improvement compared with the original low-density signals.
