Mai Zhaoxu, Lin Yuexing, Sun Jingying, Wang Chenhui, Yang Gongzheng, Wang Chengxin
School of Materials Science and Engineering, Sun Yat-Sen (Zhongshan) University, Guangzhou, 510275, People's Republic of China.
Instrumental Analysis and Research Center, Sun Yat-Sen (Zhongshan) University, Guangzhou, 510275, People's Republic of China.
Nanomicro Lett. 2025 May 19;17(1):259. doi: 10.1007/s40820-025-01773-6.
Crystallographic engineering of Zn anodes to favor the exposure of (002) planes is an effective approach for improving stability in aqueous electrolytes. However, achieving non-epitaxial electrodeposition with a pronounced (002) texture and maintaining this orientation during extended cycling remains challenging. This study questions the prevailing notion that a single (002)-textured Zn anode inherently ensures superior stability, showing that such anodes cannot sustain their texture in ZnSO electrolytes. We then introduced a novel electrolyte additive, benzyltriethylammonium chloride (TEBAC), which preserves the (002) texture over prolonged cycling. Furthermore, we successfully converted commercial Zn foils into highly crystalline (002)-textured Zn without any pretreatment. Experiments and theoretical calculations revealed that the cationic TEBA selectively adsorbs onto the anode surface, promoting the exposure of the Zn(002) plane and suppressing dendrite formation. A critical discovery was the pitting corrosion caused by chloride ions from TEBAC, which we mitigated by anion substitution. This modification leads to a remarkable lifespan of 375 days for the Zn||Zn symmetric cells at 1 mA cm and 1 mAh cm. Furthermore, a TEBA-modified Zn||VO full cell demonstrates high specific capacity and robust cycle stability at 10.0 A g. These results provide valuable insights and strategies for developing long-life Zn ion batteries.
对锌阳极进行晶体工程设计以促进(002)面的暴露是提高其在水性电解质中稳定性的有效方法。然而,实现具有明显(002)织构的非外延电沉积并在长时间循环过程中保持这种取向仍然具有挑战性。本研究对一种普遍观点提出质疑,即单一的(002)织构锌阳极本质上能确保卓越的稳定性,研究表明这种阳极在硫酸锌电解质中无法维持其织构。然后,我们引入了一种新型电解质添加剂苄基三乙基氯化铵(TEBAC),它能在长时间循环中保持(002)织构。此外,我们成功地将商业锌箔转化为高度结晶的(002)织构锌,无需任何预处理。实验和理论计算表明,阳离子TEBA选择性吸附在阳极表面,促进锌(002)面的暴露并抑制枝晶形成。一个关键发现是TEBAC中的氯离子引起的点蚀,我们通过阴离子取代减轻了这种腐蚀。这种改性使锌||锌对称电池在1 mA cm和1 mAh cm下的显著寿命达到375天。此外,TEBA改性的锌||钒全电池在10.0 A g下表现出高比容量和强大的循环稳定性。这些结果为开发长寿命锌离子电池提供了有价值的见解和策略。
