短时间吸气时的气流动力学

Dynamics of airflow in a short inhalation.

作者信息

Bates A J, Doorly D J, Cetto R, Calmet H, Gambaruto A M, Tolley N S, Houzeaux G, Schroter R C

出版信息

J R Soc Interface. 2015 Jan 6;12(102):20140880. doi: 10.1098/rsif.2014.0880.

Abstract

During a rapid inhalation, such as a sniff, the flow in the airways accelerates and decays quickly. The consequences for flow development and convective transport of an inhaled gas were investigated in a subject geometry extending from the nose to the bronchi. The progress of flow transition and the advance of an inhaled non-absorbed gas were determined using highly resolved simulations of a sniff 0.5 s long, 1 l s⁻¹ peak flow, 364 ml inhaled volume. In the nose, the distribution of airflow evolved through three phases: (i) an initial transient of about 50 ms, roughly the filling time for a nasal volume, (ii) quasi-equilibrium over the majority of the inhalation, and (iii) a terminating phase. Flow transition commenced in the supraglottic region within 20 ms, resulting in large-amplitude fluctuations persisting throughout the inhalation; in the nose, fluctuations that arose nearer peak flow were of much reduced intensity and diminished in the flow decay phase. Measures of gas concentration showed non-uniform build-up and wash-out of the inhaled gas in the nose. At the carina, the form of the temporal concentration profile reflected both shear dispersion and airway filling defects owing to recirculation regions.

摘要

在快速吸气(如嗅吸)过程中,气道内的气流加速并迅速衰减。在从鼻子到支气管的人体模型中,研究了气流发展和吸入气体对流传输的后果。使用高分辨率模拟,对一次时长0.5秒、峰值流速1升/秒、吸入体积364毫升的嗅吸进行模拟,确定了气流转变的过程以及吸入的未吸收气体的推进情况。在鼻子中,气流分布经历三个阶段:(i)约50毫秒的初始瞬态,大致为鼻腔容积的填充时间;(ii)在大部分吸气过程中的准平衡阶段;(iii)终止阶段。气流转变在声门上区域20毫秒内开始,导致在整个吸气过程中持续存在大幅度波动;在鼻子中,接近峰值流速时出现的波动强度大大降低,并在气流衰减阶段减弱。气体浓度测量结果显示,鼻子中吸入气体的积累和排出不均匀。在隆突处,时间浓度曲线的形式既反映了剪切扩散,也反映了由于回流区域导致的气道填充缺陷。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/3d94/4277078/ebb785e83e82/rsif20140880-g1.jpg
