Compensation Method for Die Shift Caused by Flow Drag Force in Wafer-Level Molding Process.

Wafer-level packaging (WLP) is a next-generation semiconductor packaging technology that is important for realizing high-performance and ultra-thin semiconductor devices. However, the molding process, which is a part of the WLP process, has various problems such as a high defect rate and low predictability. Among the various defect factors, the die shift primarily determines the quality of the final product; therefore, predicting the die shift is necessary to achieve high-yield production in WLP. In this study, the die shift caused by the flow drag force of the epoxy molding compound (EMC) is evaluated from the die shift of a debonded molding wafer. Experimental and analytical methods were employed to evaluate the die shift occurring during each stage of the molding process and that resulting from the geometrical changes after the debonding process. The die shift caused by the EMC flow drag force is evaluated from the data on die movements due to thermal contraction/expansion and warpage. The relationship between the die shift and variation in the die gap is determined through regression analysis in order to predict the die shift due to the flow drag force. The results can be used for die realignment by predicting and compensating for the die shift.
