利用原位磁粒子光谱仪(INSPECT)跟踪超顺磁纳米粒子的生长。

Tracking the Growth of Superparamagnetic Nanoparticles with an In-Situ Magnetic Particle Spectrometer (INSPECT).

机构信息

Institute of Medical Engineering, University of Lübeck, Ratzeburger Allee 160, Lübeck, Germany.

出版信息

Sci Rep. 2019 Jul 22;9(1):10538. doi: 10.1038/s41598-019-46882-6.

Abstract

Magnetic Particle Spectroscopy (MPS) is a measurement technique to determine the magnetic properties of superparamagnetic iron oxide nanoparticles (SPIONs) in an oscillating magnetic field as applied in Magnetic Particle Imaging (MPI). State of the art MPS devices are solely capable of measuring the magnetization response of the SPIONs to an oscillatory magnetic excitation retrospectively, i.e. after the synthesis process. In this contribution, a novel in-situ magnetic particle spectrometer (INSPECT) is presented, which can be used to monitor the entire synthesis process from particle genesis via growth to the stable colloidal suspension of the nanoparticles in real time. The device is suitable for the use in a biochemistry environment. It has a chamber size of 72 mm such that a 100 ml reaction flask can be used for synthesis. For an alkaline-based precipitation, the change of magnetic properties of SPIONs during the nucleation and growth phase of the synthesis is demonstrated. The device is able to record the changes in the amplitude and phase spectra, and, in turn, the hysteresis. Hence, it is a powerful tool for an in-depth understanding of the nanoparticle formation dynamics during the synthesis process.

摘要

磁性粒子光谱学(MPS)是一种测量技术,用于在应用于磁粒子成像(MPI)的振荡磁场中确定超顺磁氧化铁纳米粒子(SPION)的磁性特性。最先进的 MPS 设备仅能够回顾性地测量 SPION 对振荡磁激励的磁化响应,即在合成过程之后。在本贡献中,提出了一种新型的原位磁性粒子光谱仪(INSPECT),它可以用于实时监测从粒子生成到生长再到纳米粒子稳定胶体悬浮的整个合成过程。该设备适用于生化环境。它的腔室尺寸为 72mm,因此可以使用 100ml 的反应瓶进行合成。对于基于碱性的沉淀,展示了 SPIONs 在合成的成核和生长阶段的磁性变化。该设备能够记录幅度和相位谱的变化,进而记录磁滞回线。因此,它是深入了解合成过程中纳米颗粒形成动力学的有力工具。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/a7dc/6646392/4a0a96f53f5f/41598_2019_46882_Fig1_HTML.jpg
