BMC Med Imaging. 2020 Feb 10;20(1):14. doi: 10.1186/s12880-020-0419-0.
Our study aims to reveal whether the low b-values distribution, high b-values upper limit, and the number of excitation (NEX) influence the accuracy of the intravoxel incoherent motion (IVIM) parameter derived from multi-b-value diffusion-weighted imaging (DWI) in the brain.
This prospective study was approved by the local Ethics Committee and informed consent was obtained from each participant. The five consecutive multi-b DWI with different b-value protocols (0-3500 s/mm) were performed in 22 male healthy volunteers on a 3.0-T MRI system. The IVIM parameters from normal white matter (WM) and gray matter (GM) including slow diffusion coefficient (D), fast perfusion coefficient (D*) and perfusion fraction (f) were compared for differences among defined groups with different IVIM protocols by one-way ANOVA.
The D* and f value of WM or GM in groups with less low b-values distribution (less than or equal to 5 b-values) were significantly lower than ones in any other group with more low b-values distribution (all P < 0.05), but no significant differences among groups with more low b-values distribution (P > 0.05). In addition, no significant differences in the D, D* and f value of WM or GM were found between group with one and more NEX of low b-values distribution (all P > 0.05). IVIM parameters in normal WM and GM strongly depended on the choice of the high b-value upper limit.
Metrics of IVIM parameters can be affected by low and high b value distribution. Eight low b-values distribution with high b-value upper limit of 800-1000 s/mm may be the relatively proper set when performing brain IVIM studies.
本研究旨在探讨低 b 值分布、高 b 值上限和激发次数（NEX）是否会影响多 b 值扩散加权成像（DWI）脑内体素内不相干运动（IVIM）参数的准确性。
本前瞻性研究获得了当地伦理委员会的批准，并获得了每位参与者的知情同意。在 3.0T MRI 系统上对 22 名男性健康志愿者进行了 5 次连续的多 b 值 DWI，b 值方案不同（0-3500 s/mm）。通过单因素方差分析比较了不同 IVIM 方案定义组之间正常白质（WM）和灰质（GM）中 IVIM 参数（慢扩散系数 D、快灌注系数 D*和灌注分数 f）的差异。
低 b 值分布（小于或等于 5 个 b 值）较少的组的 WM 或 GM 的 D和 f 值显著低于其他低 b 值分布较多的组（均 P<0.05），但低 b 值分布较多的组之间无显著差异（P>0.05）。此外，低 b 值分布 NEX 为 1 次和更多次的 WM 或 GM 的 D、D和 f 值之间无显著差异（均 P>0.05）。正常 WM 和 GM 的 IVIM 参数强烈依赖于高 b 值上限的选择。
IVIM 参数的指标可能受到低 b 值和高 b 值分布的影响。在进行脑 IVIM 研究时，8 个低 b 值分布（高 b 值上限为 800-1000 s/mm）可能是比较合适的设置。
