Figueroa-Lopez Kelly J, Cabedo Luis, Lagaron Jose M, Torres-Giner Sergio
Novel Materials and Nanotechnology Group, Institute of Agrochemistry and Food Technology (IATA), Spanish National Research Council (CSIC), Paterna, Spain.
Polymers and Advanced Materials Group (PIMA), Universitat Jaume I (UJI), Castellón de la Plana, Spain.
Front Nutr. 2020 Sep 3;7:140. doi: 10.3389/fnut.2020.00140. eCollection 2020.
In this research, different contents of eugenol in the 2.5-25 wt.% range were first incorporated into ultrathin fibers of poly(3-hydroxybutyrate--3-hydroxyvalerate) (PHBV) by electrospinning and then subjected to annealing to obtain antimicrobial monolayers. The most optimal concentration of eugenol in the PHBV monolayer was 15 wt.% since it showed high electrospinnability and thermal stability and also yielded the highest bacterial reduction against () and (). This eugenol-containing monolayer was then selected to be applied as an interlayer between a structural layer made of a cast-extruded poly(3-hydroxybutyrate) (PHB) sheet and a commercial PHBV film as the food contact layer. The whole system was, thereafter, annealed at 160°C for 10 s to develop a novel multilayer active packaging material. The resultant multilayer showed high hydrophobicity, strong adhesion and mechanical resistance, and improved barrier properties against water vapor and limonene vapors. The antimicrobial activity of the multilayer structure was also evaluated in both open and closed systems for up to 15 days, showing significant reductions (R ≥ 1 and < 3) for the two strains of food-borne bacteria. Higher inhibition values were particularly attained against due to the higher activity of eugenol against the cell membrane of Gram positive (G+) bacteria. The multilayer also provided the highest antimicrobial activity for the closed system, which better resembles the actual packaging and it was related to the headspace accumulation of the volatile compounds. Hence, the here-developed multilayer fully based on polyhydroxyalkanoates (PHAs) shows a great deal of potential for antimicrobial packaging applications using biodegradable materials to increase both quality and safety of food products.
在本研究中,首先通过静电纺丝将2.5-25 wt.%范围内不同含量的丁香酚掺入聚(3-羟基丁酸酯-3-羟基戊酸酯)(PHBV)超细微纤维中,然后进行退火处理以获得抗菌单层。PHBV单层中丁香酚的最佳浓度为15 wt.%,因为它表现出高可纺性和热稳定性,并且对()和()产生的细菌减少率最高。然后选择这种含丁香酚的单层作为由流延挤出的聚(3-羟基丁酸酯)(PHB)片材制成的结构层与作为食品接触层的商用PHBV薄膜之间的中间层。此后,将整个系统在160°C下退火10 s,以开发一种新型多层活性包装材料。所得多层材料表现出高疏水性、强粘附性和机械抗性,并改善了对水蒸气和柠檬烯蒸气的阻隔性能。还在开放和封闭系统中对多层结构的抗菌活性进行了长达15天的评估,结果表明两种食源细菌菌株的数量显著减少(R≥1且<3)。由于丁香酚对革兰氏阳性(G+)细菌细胞膜的活性较高,对()尤其获得了更高的抑制值。该多层材料在封闭系统中也具有最高的抗菌活性,该系统更类似于实际包装,并且这与挥发性化合物的顶空积累有关。因此,这里开发的完全基于聚羟基脂肪酸酯(PHA)的多层材料在使用可生物降解材料的抗菌包装应用中显示出巨大潜力,可提高食品的质量和安全性。
