Bützer Peter, Brühwiler Dominik, Bützer Marcel Roland, Al-Godari Nassim, Cadalbert Michelle, Giger Mathias, Schär Sandro
Isantin GmbH, 9450 Altstätten, Switzerland.
Institute of Chemistry and Biotechnology, Zürich University of Applied Sciences (ZHAW), 8820 Wädenswil, Switzerland.
Materials (Basel). 2022 Jan 24;15(3):883. doi: 10.3390/ma15030883.
The biogenic substance E-indigo can form supramolecular, hydrophobic structures using self-organization. These structures show a low coefficient of friction as a gliding layer against polar surfaces. The formation of primary particles with platelet morphology based on hydrogen-bonded E-indigo molecules is ideal to produce the gliding layer. Structures with excellent gliding properties can be achieved by means of directed friction and high pressure, as well as through tempering. The resulting hard, thin gliding layer of E-indigo does not easily absorb dirt and, thus, prevents a rapid increase in friction. Field tests on snow, with cross-country skis, have shown promising results in comparison to fluorinated and non-fluorinated waxes. Based on quantitative structure-activity relationship (QSAR) data for E-indigo, and its isomers and tautomers, it has been demonstrated that both the application and abrasion of the thin indigo layers are harmless to health, and are ecologically benign and, therefore, sustainable.
生物源物质E-靛蓝可通过自组装形成超分子疏水结构。这些结构作为极性表面的滑动层,摩擦系数较低。基于氢键结合的E-靛蓝分子形成具有血小板形态的初级颗粒,是制备滑动层的理想选择。通过定向摩擦、高压以及回火处理,可以获得具有优异滑动性能的结构。所得坚硬、薄的E-靛蓝滑动层不易吸附污垢,从而防止摩擦力迅速增加。与含氟和不含氟的蜡相比,在雪地上使用越野滑雪板进行的现场测试显示出了良好的效果。基于E-靛蓝及其异构体和互变异构体的定量构效关系(QSAR)数据,已证明薄靛蓝层的应用和磨损对健康无害,并且在生态上是良性的,因此是可持续的。
