智能座椅传感器系统的开发与深度学习算法的坐姿分类。

Development of a Smart Chair Sensors System and Classification of Sitting Postures with Deep Learning Algorithms.

机构信息

Polytechnic Department of Engineering and Architecture, University of Udine, Via delle Scienze 206, 33100 Udine, Italy.

Institute for Smart Systems Technologies, Alpen-Adria University, 9020 Klagenfurt, Austria.

出版信息

Sensors (Basel). 2022 Jul 26;22(15):5585. doi: 10.3390/s22155585.

Abstract

Nowadays in modern societies, a sedentary lifestyle is almost inevitable for a majority of the population. Long hours of sitting, especially in wrong postures, may result in health complications. A smart chair with the capability to identify sitting postures can help reduce health risks induced by a modern lifestyle. This paper presents the design, realization and evaluation of a new smart chair sensors system capable of sitting postures identification. The system consists of eight pressure sensors placed on the chair's sitting cushion and the backrest. A signal acquisition board was designed from scratch to acquire data generated by the pressure sensors and transmit them via a Wi-Fi network to a purposely developed graphical user interface which monitors and stores the acquired sensors' data on a computer. The designed system was tested by means of an extensive sitting experiment involving 40 subjects, and from the acquired data, the classification of the respective sitting postures out of eight possible postures was performed. Hereby, the performance of seven deep-learning algorithms was assessed. The best accuracy of 91.68% was achieved by an echo memory network model. The designed smart chair sensors system is simple and versatile, low cost and accurate, and it can easily be deployed in several smart chair environments, both for public and private contexts.

摘要

如今,在现代社会中,久坐的生活方式对大多数人来说几乎是不可避免的。长时间坐着,尤其是坐姿不正确,可能会导致健康问题。一款能够识别坐姿的智能椅子可以帮助降低现代生活方式带来的健康风险。本文介绍了一种新的智能椅子传感器系统的设计、实现和评估,该系统能够识别坐姿。该系统由放置在椅子坐垫和靠背上的八个压力传感器组成。我们从头开始设计了一个信号采集板,用于采集压力传感器产生的数据,并通过 Wi-Fi 网络将其传输到专门开发的图形用户界面,该界面实时监测并存储计算机上采集到的传感器数据。通过涉及 40 名受试者的广泛坐姿实验对所设计的系统进行了测试,并根据所获得的数据,对八种可能坐姿中的各自坐姿进行了分类。在此,评估了七种深度学习算法的性能。回声记忆网络模型的准确率达到了 91.68%。所设计的智能椅子传感器系统简单、通用、成本低且准确率高,并且可以轻松部署在多个智能椅子环境中,无论是公共环境还是私人环境。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0940/9371131/c58a5582f3a7/sensors-22-05585-g001.jpg
