Multi-nuclear magnetic resonance spectroscopy: state of the art and future directions.

作者信息

Wei Yi, Yang Caiwei, Jiang Hanyu, Li Qian, Che Feng, Wan Shang, Yao Shan, Gao Feifei, Zhang Tong, Wang Jiazheng, Song Bin

机构信息

Department of Radiology, West China Hospital, Sichuan University, No. 37, Guoxue Alley, Chengdu, 610041, People's Republic of China.

Clinical & Technical Support, Philips Healthcare, Beijing, China.

出版信息

Insights Imaging. 2022 Aug 17;13(1):135. doi: 10.1186/s13244-022-01262-z.


DOI:10.1186/s13244-022-01262-z
PMID:35976510
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC9382599/
Abstract

With the development of heteronuclear fluorine, sodium, phosphorus, and other probes and imaging technologies as well as the optimization of magnetic resonance imaging (MRI) equipment and sequences, multi-nuclear magnetic resonance (multi-NMR) has enabled localize molecular activities in vivo that are central to a variety of diseases, including cardiovascular disease, neurodegenerative pathologies, metabolic diseases, kidney, and tumor, to shift from the traditional morphological imaging to the molecular imaging, precision diagnosis, and treatment mode. However, due to the low natural abundance and low gyromagnetic ratios, the clinical application of multi-NMR has been hampered. Several techniques have been developed to amplify the NMR sensitivity such as the dynamic nuclear polarization, spin-exchange optical pumping, and brute-force polarization. Meanwhile, a wide range of nuclei can be hyperpolarized, such as H, He, C,  N, P, and Xe. The signal can be increased and allows real-time observation of biological perfusion, metabolite transport, and metabolic reactions in vivo, overcoming the disadvantages of conventional magnetic resonance of low sensitivity. HP-NMR imaging of different nuclear substrates provides a unique opportunity and invention to map the metabolic changes in various organs without invasive procedures. This review aims to focus on the recent applications of multi-NMR technology not only in a range of preliminary animal experiments but also in various disease spectrum in human. Furthermore, we will discuss the future challenges and opportunities of this multi-NMR from a clinical perspective, in the hope of truly bridging the gap between cutting-edge molecular biology and clinical applications.

摘要
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/7cd6b1a980dd/13244_2022_1262_Fig10_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/5c8c23798265/13244_2022_1262_Fig1_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/a29f43871b96/13244_2022_1262_Fig2_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/a1a59f7aa958/13244_2022_1262_Fig3_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/058c847f7361/13244_2022_1262_Fig4_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/d449b489bc7c/13244_2022_1262_Fig5_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/001d91d10be5/13244_2022_1262_Fig6_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/d01907f4820b/13244_2022_1262_Fig7_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/777dafa11824/13244_2022_1262_Fig8_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/5a2a828c5be8/13244_2022_1262_Fig9_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/7cd6b1a980dd/13244_2022_1262_Fig10_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/5c8c23798265/13244_2022_1262_Fig1_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/a29f43871b96/13244_2022_1262_Fig2_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/a1a59f7aa958/13244_2022_1262_Fig3_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/058c847f7361/13244_2022_1262_Fig4_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/d449b489bc7c/13244_2022_1262_Fig5_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/001d91d10be5/13244_2022_1262_Fig6_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/d01907f4820b/13244_2022_1262_Fig7_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/777dafa11824/13244_2022_1262_Fig8_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/5a2a828c5be8/13244_2022_1262_Fig9_HTML.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/0493/9385900/7cd6b1a980dd/13244_2022_1262_Fig10_HTML.jpg
