Department of Biomedical Engineering, Beijing International Science and Technology Cooperation Base for Intelligent Physiological Measurement and Clinical Transformation, Beijing University of Technology, Beijing, China.
Beijing Tongren Eye Center, Beijing Ophthalmology & Visual Sciences Key Lab, Beijing Tongren Hospital, Capital Medical University, Beijing, China.
Transl Vis Sci Technol. 2023 Jan 3;12(1):22. doi: 10.1167/tvst.12.1.22.
Automatic multilabel classification of multiple fundus diseases is of importance for ophthalmologists. This study aims to design an effective multilabel classification model that can automatically classify multiple fundus diseases based on color fundus images.
We proposed a multilabel fundus disease classification model based on a convolutional neural network to classify normal and seven categories of common fundus diseases. Specifically, an attention mechanism was introduced into the network to further extract information features from color fundus images. The fundus images with eight categories of labels were applied to train, validate, and test our model. We employed the validation accuracy, area under the receiver operating characteristic curve (AUC), and F1-score as performance metrics to evaluate our model.
Our proposed model achieved better performance with a validation accuracy of 94.27%, an AUC of 85.80%, and an F1-score of 86.08%, compared to two state-of-the-art models. Most important, the number of training parameters has dramatically dropped by three and eight times compared to the two state-of-the-art models.
This model can automatically classify multiple fundus diseases with not only excellent accuracy, AUC, and F1-score but also significantly fewer training parameters and lower computational cost, providing a reliable assistant in clinical screening.
The proposed model can be widely applied in large-scale multiple fundus disease screening, helping to create more efficient diagnostics in primary care settings.
自动对多种眼底疾病进行多标签分类对眼科医生来说非常重要。本研究旨在设计一种有效的多标签分类模型,能够基于眼底彩色图像自动对多种眼底疾病进行分类。
我们提出了一种基于卷积神经网络的多标签眼底疾病分类模型,用于对正常和七种常见眼底疾病进行分类。具体来说,我们在网络中引入了注意力机制,以进一步从眼底彩色图像中提取信息特征。我们使用八类标签的眼底图像来训练、验证和测试我们的模型。我们采用验证准确率、接收者操作特征曲线下的面积(AUC)和 F1 分数作为性能指标来评估我们的模型。
与两种最先进的模型相比,我们提出的模型在验证准确率为 94.27%、AUC 为 85.80%和 F1 分数为 86.08%时表现出更好的性能。最重要的是,与两种最先进的模型相比,我们的模型的训练参数数量分别减少了三到八倍。
该模型不仅具有出色的准确性、AUC 和 F1 分数,而且还具有显著更少的训练参数和更低的计算成本,可以为临床筛查提供可靠的辅助。
