Díaz-Perete Daniel, Hermoso-Orzáez Manuel Jesús, Carmo-Calado Luís, Martín-Doñate Cristina, Terrados-Cepeda Julio
Department of Graphic Engineering, Design and Projects, University of Jaén, 23071 Jaén, Spain.
Centre for Advanced Studies in Energy and Environment, University of Jaén, 23071 Jaén, Spain.
Polymers (Basel). 2023 Feb 1;15(3):750. doi: 10.3390/polym15030750.
One of the polymeric materials used in the most common 3D printers is poly(ethylene terephthalate) glycol (PETG). It represents, in world terms, around 2.3% of polymeric raw material used in additive manufacturing. However, after processing this material, its properties change irreversibly. A significant amount of waste is produced around the world, and its disposal is usually destined for landfill or incineration, which can generate an important issue due to the high environmental risks. Polymer waste from 3D printing, hereinafter 3DPPW, has a relatively high calorific value and adequate characteristics to be valued in thermochemical processes. Gasification emerges as an innovative and alternative solution for recovering energy from 3DPPW, mixed with residues of lignocellulosic origin, and presents some environmental advantages compared to other types of thermochemical treatments, since the gasification process releases smaller amounts of NOx into the atmosphere, SOx, and CO. In the case of the study, co-gasification of olive pomace (OLB) was carried out with small additions of 3DPPW (10% and 20%) at different temperatures. Comparing the different gasifications (100% OLB, 90% OLB + 10% 3DPPW, 80% OLB + 20% 3DPPW), the best results for the synthesis gas were obtained for the mixture of 10% 3DPPW and 90% olive pomace (OLB), having a lower calorific value of 6.16 MJ/m, synthesis gas yield of 3.19%, and cold gas efficiency of 87.85% for a gasification temperature of 750 °C. In addition, the results demonstrate that the addition of 3DPPW improved the quality of syngas, especially between temperatures of 750 and 850 °C. Including polymeric 3D printing materials in the context of the circular economy and extending their life cycle helps to improve the efficiency of subsequent industrial processes, reducing process costs in general, thanks to the new industrial value acquired by the generated by-products.
最常见的3D打印机所使用的聚合材料之一是聚对苯二甲酸乙二酯二醇(PETG)。从全球范围来看,它占增材制造中使用的聚合原材料的2.3%左右。然而,在对这种材料进行加工后,其性能会发生不可逆的变化。全球产生了大量的废料,其处理方式通常是填埋或焚烧,由于环境风险高,这可能会引发重大问题。3D打印产生的聚合物废料(以下简称3DPPW)具有相对较高的热值和适当的特性,可在热化学过程中加以利用。气化作为一种创新的替代解决方案,可从3DPPW中回收能量,3DPPW与木质纤维素来源的残渣混合使用,与其他类型的热化学处理相比,气化具有一些环境优势,因为气化过程向大气中释放的氮氧化物、硫氧化物和一氧化碳的量较少。在该研究中,在不同温度下,对添加少量3DPPW(10%和20%)的橄榄果渣(OLB)进行了共气化。比较不同的气化方式(100% OLB、90% OLB + 10% 3DPPW、80% OLB + 20% 3DPPW),对于10% 3DPPW和90%橄榄果渣(OLB)的混合物,合成气的效果最佳,在750℃的气化温度下,其热值较低,为6.16 MJ/m,合成气产率为3.19%,冷煤气效率为87.85%。此外,结果表明,添加3DPPW提高了合成气的质量,特别是在750至850℃的温度范围内。将聚合物3D打印材料纳入循环经济背景并延长其生命周期,有助于提高后续工业过程的效率,总体上降低加工成本,这得益于所产生的副产品获得的新工业价值。
