In deep-seated brain tumors, adequate preoperative planning is mandatory to assess the best surgical corridor to obtain maximal safe resection. Functional diffusor tensor imaging (DTI) tractography based on navigated transcranial magnetic stimulation (nTMS) motor mapping has proven to be a valid preoperative examination method in adults. The aim of this paper is to present the application of nTMS and functional DTI tractography in a series of pediatric diencephalic tumors. Three patients affected by thalamic (one) and thalamopeduncular tumor (two) were successfully examined with nTMS motor mapping and DTI tractography between October 2020 and October 2021 (F:M 3:0, mean age 12 years ± 0.8). Cortical representation of leg, hand and mouth were determined in the affected hemisphere and the positive stimulation spots were set as seeds point for tractography. Mapping of the motor cortex and tracts reconstruction for leg and hand were successful in all patients, while facial function was properly mapped in one patient only. In all cases, the procedure was well tolerated and no adverse events were recorded. Spatial relationships between tumor and functional tissue guided the surgical planning. Extent of the resection varied from 96.1% to 100% with a postoperative new motor deficit in one patient. nTMS and DTI fiber tracking is a feasible, effective and well-tolerated method to identify motor pathway in deep-seated lesion in pediatric population.
