Physikalisch-Technische Bundesanstalt, Abbestr. 2-12, 10587, Berlin, Germany.
Department of Cardiology, Angiology and Intensive Care Medicine, Deutsches Herzzentrum der Charité, Charitéplatz 1, 10117, Berlin, Germany.
Sci Rep. 2024 Feb 21;14(1):4253. doi: 10.1038/s41598-024-54784-5.
Magnetic Particle Imaging (MPI) is an advanced and powerful imaging modality for visualization and quantitative real-time detection of magnetic nanoparticles (MNPs). This opens the possibility of tracking cells in vivo once they have been loaded by MNPs. Imaging modalities such as optical imaging, X-ray computed tomography (CT), positron emission tomography (PET), single photon emission computed tomography (SPECT), and magnetic resonance imaging (MRI) face limitations, from depth of penetration and radiation exposure to resolution and quantification accuracy. MPI addresses these challenges, enabling radiation-free tracking of MNP-loaded cells with precise quantification. However, the real-time tracking of MNP-loaded cells with MPI has not been demonstrated yet. This study establishes real-time quantitative tracking of MNP-loaded cells. Therefore, THP-1 monocytes were loaded with three different MNP systems, including the MPI gold standard Resovist and Synomag. The real-time MPI experiments reveal different MPI resolution behaviors of the three MNP systems after cellular uptake. Real-time quantitative imaging was achieved by time-resolved cell number determination and comparison with the number of inserted cells. About 95% of the inserted cells were successfully tracked in a controlled phantom environment. These results underline the potential of MPI for real-time investigation of cell migration and interaction with tissue in vivo.
磁粒子成像(MPI)是一种用于可视化和实时定量检测磁性纳米粒子(MNPs)的先进且强大的成像方式。这为在 MNPs 加载后对细胞进行体内追踪提供了可能。光学成像、X 射线计算机断层扫描(CT)、正电子发射断层扫描(PET)、单光子发射计算机断层扫描(SPECT)和磁共振成像(MRI)等成像方式存在着穿透深度、辐射暴露、分辨率和定量准确性等方面的限制。MPI 解决了这些挑战,实现了对 MNPs 负载细胞的无辐射追踪和精确定量。然而,MPI 对 MNPs 负载细胞的实时追踪尚未得到证实。本研究建立了 MNPs 负载细胞的实时定量追踪。因此,用三种不同的 MNPs 系统负载 THP-1 单核细胞,包括 MPI 的金标准 Resovist 和 Synomag。细胞摄取后,实时 MPI 实验揭示了三种 MNPs 系统的不同 MPI 分辨率行为。通过时间分辨细胞数量的确定和与插入细胞数量的比较,实现了实时定量成像。在受控的模拟环境中,约 95%的插入细胞被成功追踪。这些结果强调了 MPI 用于实时研究细胞迁移和与体内组织相互作用的潜力。
