微型光学成像系统中的深度扫描技术[特邀报告]

Technologies for depth scanning in miniature optical imaging systems [Invited].

作者信息

Liu Yuehan, Zhang Haolin, Li Xingde

机构信息

Department of Electrical and Computer Engineering, Johns Hopkins University, Baltimore, Maryland 21218, USA.

Department of Biomedical Engineering, Johns Hopkins University, Baltimore, Maryland 21205, USA.

出版信息

Biomed Opt Express. 2023 Nov 29;14(12):6542-6562. doi: 10.1364/BOE.507078. eCollection 2023 Dec 1.

Abstract

Biomedical optical imaging has found numerous clinical and research applications. For achieving 3D imaging, depth scanning presents the most significant challenge, particularly in miniature imaging devices. This paper reviews the state-of-art technologies for depth scanning in miniature optical imaging systems, which include two general approaches: 1) physically shifting part of or the entire imaging device to allow imaging at different depths and 2) optically changing the focus of the imaging optics. We mainly focus on the second group of methods, introducing a wide variety of tunable microlenses, covering the underlying physics, actuation mechanisms, and imaging performance. Representative applications in clinical and neuroscience research are briefly presented. Major challenges and future perspectives of depth/focus scanning technologies for biomedical optical imaging are also discussed.

摘要

生物医学光学成像已在众多临床和研究应用中得到应用。为了实现三维成像,深度扫描带来了最严峻的挑战,尤其是在微型成像设备中。本文综述了微型光学成像系统中深度扫描的最新技术,包括两种一般方法:1)物理移动部分或整个成像设备以允许在不同深度成像,以及2)光学改变成像光学器件的焦点。我们主要关注第二类方法,介绍了各种各样的可调微透镜,涵盖其基础物理、驱动机制和成像性能。还简要介绍了在临床和神经科学研究中的代表性应用。同时也讨论了生物医学光学成像深度/焦点扫描技术的主要挑战和未来展望。
