基于低成本、无真空的雾状化学气相沉积外延生长方法的氧化镓材料与器件的最新进展。

Recent progress of GaO materials and devices based on the low-cost, vacuum-free Mist-CVD epitaxial growth method.

作者信息

Zhang Zeyulin, Yan Pengru, Song Qingwen, Chen Haifeng, Zhang Wentao, Yuan Hao, Du Fengyu, Liu Dinghe, Chen Dazheng, Zhang Yuming

机构信息

Wide Bandgap Semiconductor Technology Disciplines State Key Laboratory, School of Microelectronics, Xidian University, Xi'an 710071, China.

Xidian-Wuhu Research Institute, Wuhu 241000, China.

出版信息

Fundam Res. 2023 Feb 26;4(5):1292-1305. doi: 10.1016/j.fmre.2023.01.001. eCollection 2024 Sep.

Abstract

Compared with silicon, gallium nitride, silicon carbide, and other traditional semiconductors, gallium oxide (GaO) who possesses, an ultrawide bandgap of approximately 5.0 eV and a higher breakdown field strength of approximately 8 MV/cm has attracted increasing attention from researchers, especially for the potential application in power devices. Moreover, GaO material has natural ultraviolet detection ability for photodetectors due to its ultrawide bandgap. These future commercial applications put forward an urgent require for high-quality epitaxial GaO material in an efficient growth method at a lower cost. Although there are some conventional methods for single crystal GaO film epitaxial growth such as MBE and MOCVD, these methods always need a vacuum growth environment and expensive equipment. As a fast-growing method, Mist-CVD gives the growth of GaO in a vacuum-free, process-simple, and low-cost method, which will greatly reduce the cost and facilitate the development of GaO. This review has summarizes the Mist-CVD epitaxy growth mechanism of GaO, recent progress in the GaO film epitaxial growth, and various device properties based on the Mist-CVD method. Our work aims to provide help for the development of GaO material growth and device applications.

摘要

与硅、氮化镓、碳化硅等传统半导体相比,氧化镓(GaO)具有约5.0 eV的超宽带隙和约8 MV/cm的更高击穿场强,已引起研究人员越来越多的关注,特别是在功率器件方面的潜在应用。此外,由于其超宽带隙,GaO材料对光电探测器具有天然的紫外探测能力。这些未来的商业应用迫切需要以低成本、高效的生长方法获得高质量的外延GaO材料。虽然有一些用于单晶GaO薄膜外延生长的传统方法,如分子束外延(MBE)和金属有机化学气相沉积(MOCVD),但这些方法总是需要真空生长环境和昂贵的设备。作为一种快速生长方法,雾化化学气相沉积(Mist-CVD)以无真空、工艺简单且低成本的方式实现了GaO的生长,这将大大降低成本并促进GaO的发展。本综述总结了GaO的Mist-CVD外延生长机制、GaO薄膜外延生长的最新进展以及基于Mist-CVD方法的各种器件特性。我们的工作旨在为GaO材料生长和器件应用的发展提供帮助。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/341f/11489483/6b81a22dd149/gr1.jpg
