Bégin R, Ostiguy G, Filion R, Colman N, Bertrand P
CHU Sherbrooke, Québec, Canada.
Br J Ind Med. 1993 Aug;50(8):689-98. doi: 10.1136/oem.50.8.689.
Computed tomography (CT; both conventional (CCT) and high resolution (HRCT)) scans of the thorax were evaluated to detect early asbestosis in 61 subjects exposed to asbestos dust in Québec for an average of 22(3) years and in five controls. The study was limited to consecutive cases with chest radiographs of the International Labour Organisation categories 0 or 1 determined independently. All subjects had a standard high kilovoltage posteroanterior and lateral chest radiograph, a set of 10-15 1 cm collimation CCT scans and a set of three to five 2 mm collimation HRCT scans in the upper, middle, and lower lung fields. Five experienced readers independently read each chest radiograph and sets of CT scans. On the basis of three to five readers agreeing for small opacities of the lung parenchyma, 12/46 (26%) negative chest radiographs were positive on CT scans, but 6/18 (33%) positive chest radiographs were negative on CT scan. On the basis of four to five readers agreeing on a chest radiograph, 36/66 (54%) subjects were normal (group A), 17/66 (26%) were indeterminate (group B), and 13/66 (20%) were abnormal (group C). By the combined readings of CCT and HRCT, 4/31 (13%) asbestos exposed subjects of group A were abnormal (p < 0.001), 6/17 (35%) of group B were abnormal, and in group C, 1/13 (8%) was normal, 2/13 were indeterminate, and 10/13 (77%) were abnormal. Separate readings of CCT and HRCT on distinct films in 14 subjects showed that all cases of asbestosis were abnormal on both CCT and HRCT. Inter-reader analyses by kappa statistics showed significantly better agreement for the readings of CT than the chest radiographs (p < 0.001), and for the reading of CCT than HRCT (p < 0.01). Thus CT scans of the thorax identifies significantly more irregular opacities consistent with the diagnosis of asbestosis than the chest radiograph (20 cases on CT scans v 13 on chest radiographs when four to five readers agreed, 13% of asbestos exposed subjects with normal chest radiographs or 21% of asbestos exposed subjects with normal or near normal chest radiographs. It decreased the number of indeterminate cases significantly from 17 on chest radiographs to 13 on CT scans. All cases of asbestosis detected only on CT scans were similarly seen on CCT and HRCT and did not have significant changes in lung function. The CT scans significantly reduced the inter-reader variability, despite the absence of ILO type reference films for these scans.
对61名平均接触石棉粉尘22(3)年的魁北克受试者以及5名对照者进行了胸部计算机断层扫描(CT;包括传统CT(CCT)和高分辨率CT(HRCT)),以检测早期石棉肺。该研究仅限于连续病例,这些病例的国际劳工组织分类0或1的胸部X光片由独立人员判定。所有受试者均进行了标准的高千伏后前位和侧位胸部X光片检查,以及一组10 - 15张1厘米准直的CCT扫描和一组三到五张2毫米准直的上、中、下肺野HRCT扫描。五名经验丰富的阅片者分别阅读每张胸部X光片和CT扫描片。基于三到五名阅片者对肺实质小阴影的一致判断,12/46(26%)胸部X光片阴性的病例在CT扫描中呈阳性,但6/18(33%)胸部X光片阳性的病例在CT扫描中呈阴性。基于四到五名阅片者对胸部X光片的一致判断,36/66(54%)的受试者正常(A组),17/66(26%)不确定(B组),13/66(20%)异常(C组)。通过CCT和HRCT的联合阅片,A组31名接触石棉的受试者中有4/31(13%)异常(p < 0.001),B组17名中有6/17(35%)异常,C组中,1/13(8%)正常,2/13不确定,10/13(77%)异常。对14名受试者在不同胶片上分别进行CCT和HRCT阅片显示,所有石棉肺病例在CCT和HRCT上均异常。通过kappa统计进行阅片者间分析表明,CT阅片的一致性明显优于胸部X光片(p < 0.001),CCT阅片的一致性优于HRCT(p < 0.01)。因此,胸部CT扫描比胸部X光片能识别出更多与石棉肺诊断相符的不规则阴影(当四到五名阅片者达成一致时,CT扫描发现20例,胸部X光片发现13例,胸部X光片正常的石棉接触受试者中有13%,或胸部X光片正常或接近正常的石棉接触受试者中有21%)。它显著减少了不确定病例的数量,从胸部X光片的17例降至CT扫描的13例。所有仅在CT扫描中检测到的石棉肺病例在CCT和HRCT上表现相似,且肺功能无显著变化。尽管这些扫描没有国际劳工组织类型的参考片,但CT扫描显著降低了阅片者间的变异性。
