Sanghavi Bankim J, Wolfbeis Otto S, Hirsch Thomas, Swami Nathan S
Department of Electrical and Computer Engineering, University of Virginia, Charlottesville, VA 22904 USA.
Institute of Analytical Chemistry, Chemo- and Biosensors, University of Regensburg, Regensburg, 93040 Germany.
Mikrochim Acta. 2015;182(1):1-41. doi: 10.1007/s00604-014-1308-4. Epub 2014 Jul 8.
Nanomaterial-modified detection systems represent a chief driver towards the adoption of electrochemical methods, since nanomaterials enable functional tunability, ability to self-assemble, and novel electrical, optical and catalytic properties that emerge at this scale. This results in tremendous gains in terms of sensitivity, selectivity and versatility. We review the electrochemical methods and mechanisms that may be applied to the detection of neurological drugs. We focus on understanding how specific nano-sized modifiers may be applied to influence the electron transfer event to result in gains in sensitivity, selectivity and versatility of the detection system. This critical review is structured on the basis of the Anatomical Therapeutic Chemical (ATC) Classification System, specifically ATC Code N (neurotransmitters). Specific sections are dedicated to the widely used electrodes based on the carbon materials, supporting electrolytes, and on electrochemical detection paradigms for neurological drugs and neurotransmitters within the groups referred to as ATC codes N01 to N07. We finally discuss emerging trends and future challenges such as the development of strategies for simultaneous detection of multiple targets with high spatial and temporal resolutions, the integration of microfluidic strategies for selective and localized analyte pre-concentration, the real-time monitoring of neurotransmitter secretions from active cell cultures under electro- and chemotactic cues, aptamer-based biosensors, and the miniaturization of the sensing system for detection in small sample volumes and for enabling cost savings due to manufacturing scale-up. The Electronic Supporting Material (ESM) includes review articles dealing with the review topic in last 40 years, as well as key properties of the analytes, viz., pK values, half-life of drugs and their electrochemical mechanisms. The ESM also defines analytical figures of merit of the drugs and neurotransmitters. The article contains 198 references in the main manuscript and 207 references in the Electronic Supporting Material. Figureᅟ
纳米材料修饰的检测系统是推动电化学方法应用的主要动力,因为纳米材料具有功能可调性、自组装能力以及在该尺度下出现的新颖电学、光学和催化特性。这在灵敏度、选择性和多功能性方面带来了巨大提升。我们综述了可应用于神经药物检测的电化学方法和机制。我们着重于理解如何应用特定的纳米尺寸修饰剂来影响电子转移过程,从而提高检测系统的灵敏度、选择性和多功能性。这篇批判性综述是基于解剖治疗化学(ATC)分类系统构建的,具体是ATC代码N(神经递质)。特定章节专门讨论了基于碳材料的广泛使用的电极、支持电解质以及ATC代码N01至N07组内神经药物和神经递质的电化学检测范式。我们最后讨论了新兴趋势和未来挑战,例如开发具有高空间和时间分辨率的多目标同时检测策略、整合用于选择性和局部分析物预浓缩的微流控策略、在电和趋化线索下对活性细胞培养物中神经递质分泌的实时监测、基于适配体的生物传感器,以及传感系统的小型化,以便在小样本量中进行检测并因扩大生产规模而节省成本。电子支持材料(ESM)包括过去40年中处理该综述主题的综述文章,以及分析物的关键特性,即pK值、药物半衰期及其电化学机制。ESM还定义了药物和神经递质的分析性能指标。文章在主稿件中包含198篇参考文献,在电子支持材料中包含207篇参考文献。图ᅟ
