钙钛矿太阳能组件的性价比分析

Cost-Performance Analysis of Perovskite Solar Modules.

作者信息

Cai Molang, Wu Yongzhen, Chen Han, Yang Xudong, Qiang Yinghuai, Han Liyuan

机构信息

Center for Green Research on Energy and Environmental Materials National Institute for Materials Science Tsukuba Ibaraki 305-0047 Japan.

State Key Laboratory of Metal Matrix Composites Shanghai Jiao Tong University 800 Dong Chuan RD. Minhang District Shanghai 200240 PR China.

出版信息

Adv Sci (Weinh). 2016 Sep 15;4(1):1600269. doi: 10.1002/advs.201600269. eCollection 2017 Jan.

DOI:10.1002/advs.201600269
PMID:28105403
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC5238749/
Abstract

Perovskite solar cells (PSCs) are promising candidates for the next generation of solar cells because they are easy to fabricate and have high power conversion efficiencies. However, there has been no detailed analysis of the cost of PSC modules. We selected two representative examples of PSCs and performed a cost analysis of their productions: one was a moderate-efficiency module produced from cheap materials, and the other was a high-efficiency module produced from expensive materials. The costs of both modules were found to be lower than those of other photovoltaic technologies. We used the calculated module costs to estimate the levelized cost of electricity (LCOE) of PSCs. The LCOE was calculated to be 3.5-4.9 US cents/kWh with an efficiency and lifetime of greater than 12% and 15 years respectively, below the cost of traditional energy sources.

摘要

钙钛矿太阳能电池(PSC)因其易于制造且具有高功率转换效率,成为下一代太阳能电池的有力候选者。然而,目前尚未对PSC组件的成本进行详细分析。我们选择了两个具有代表性的PSC示例,并对其生产成本进行了分析:一个是由廉价材料制成的中等效率组件,另一个是由昂贵材料制成的高效组件。结果发现,这两种组件的成本均低于其他光伏技术。我们利用计算得出的组件成本来估算PSC的平准化度电成本(LCOE)。当效率大于12%且寿命大于15年时,计算得出的LCOE为3.5 - 4.9美分/千瓦时,低于传统能源的成本。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5844/5238749/777123dde61a/ADVS-4-0-g006.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5844/5238749/b5b983ac88ca/ADVS-4-0-g001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5844/5238749/2a881e68f583/ADVS-4-0-g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5844/5238749/9f3eb0cd01ee/ADVS-4-0-g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5844/5238749/1739b6baa5df/ADVS-4-0-g004.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5844/5238749/66e9c51470a7/ADVS-4-0-g005.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5844/5238749/777123dde61a/ADVS-4-0-g006.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5844/5238749/b5b983ac88ca/ADVS-4-0-g001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5844/5238749/2a881e68f583/ADVS-4-0-g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5844/5238749/9f3eb0cd01ee/ADVS-4-0-g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5844/5238749/1739b6baa5df/ADVS-4-0-g004.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5844/5238749/66e9c51470a7/ADVS-4-0-g005.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5844/5238749/777123dde61a/ADVS-4-0-g006.jpg
