Nonrigid registration with corresponding points constraint for automatic segmentation of cardiac DSCT images.

BACKGROUND

Dual-source computed tomography (DSCT) is a very effective way for diagnosis and treatment of heart disease. The quantitative information of spatiotemporal DSCT images can be important for the evaluation of cardiac function. To avoid the shortcoming of manual delineation, it is imperative to develop an automatic segmentation technique for 4D cardiac images.

METHODS

In this paper, we implement the heart segmentation-propagation framework based on nonrigid registration. The corresponding points of anatomical substructures are extracted by using the extension of n-dimensional scale invariant feature transform method. They are considered as a constraint term of nonrigid registration using the free-form deformation, in order to restrain the large variations and boundary ambiguity between subjects.

RESULTS

We validate our method on 15 patients at ten time phases. Atlases are constructed by the training dataset from ten patients. On the remaining data the median overlap is shown to improve significantly compared to original mutual information, in particular from 0.4703 to 0.5015 ([Formula: see text]) for left ventricle myocardium and from 0.6307 to 0.6519 ([Formula: see text]) for right atrium.

CONCLUSIONS

The proposed method outperforms standard mutual information of intensity only. The segmentation errors had been significantly reduced at the left ventricle myocardium and the right atrium. The mean surface distance of using our framework is around 1.73 mm for the whole heart.
